CENTRIX™ & EVENTIX™

Chapter 3 : OPERATING MODE (continued)

PAGE 35

3-3. OPERATING WITH THE REMOTE KEYPAD (continued)

3-3-2. OPERATING IN MIXER MODE (continued)
EXAMPLES OF TRANSITION

c PIP effect:
The PIP effect allows to insert an image into another one.
• Press the PIP key, then make all the needed adjustments (duration, size, position...) with  and validate with
ENTER.
• Press the TAKE key to activate the effect (ACTION 1): the PREVIEW image is inserted into the MAIN image.
NOTE:

• You can change the image in the PIP (PREVIEW image) by selecting another input of the PREVIEW
output (ACTION 2): Press the PREVIEW (OUTPUT SELECT) key and select the needed input (the
transition operates with a fading to black)
• You can change the background image (MAIN image) by selecting another input of the MAIN output
(ACTION 3): Press the MAIN (OUTPUT SELECT) key and select the needed input (the transition
operates with a fading to black).
• To remove the PIP effect, press the TAKE key.

See Figure 21: PIP effect. Page 20.

d Title effect (or shadow title):
The TITLE effect allows to display a text onto the MAIN image. For a better readability you also can display a
shadow bar onto your text.
• Create the text to display with the computer connected to the CENTRIX

/ EVENTIX

thanks to a drawing

software like PowerPoint® (text in white onto a black background).
• Display on the MAIN output the source to titling, then pre-select the source used for create the text: the image
appears on the PREVIEW output.
• Assign the TITLE effect to one of the USER keys: Press one USER key, select title or shadow title with
and validate with ENTER, then select the duration with  and validate with ENTER.
• Press the TAKE key to activate the effect (ACTION 1): the text is now displayed onto the image of the MAIN
output.
NOTE: You can change the background image (MAIN image) by selecting another input of the MAIN output

(ACTION 2): Press the MAIN output select key and select the needed input (the transition operates with a
fading to black). To remove the TITLE effect, press the TAKE key (ACTION 3).

See Figure 22: Title effect. Page 21.

e Wipe transition:
• Assign a WIPE to one of the USER keys: Press one USER key, select a WIPE with the knob  and validate
with ENTER (for example: hor wipe > from left), then select the duration with  and validate with ENTER.
• Press the TAKE key to activate the transition: the PREVIEW image appears onto the MAIN display with a wipe
transition.

See Figures Page 22.

VIDEO OUTPUT ADJUSTMENTS

c Select the output standard (OUTPUT menu > video output > video standard > NTSC or PAL).
d Select the video "output rate" (OUTPUT menu > video output > output rate >...).
f Select the zoom mode (OUTPUT menu > video output > U/Over scan > underscan or overscan).
e Select a level of anti-flicker (OUTPUT menu > video output > flicker adj. >...).

AUDIO ADJUSTMENTS

For each AUDIO output, make the following adjustment.
c Adjust the master volume (AUDIO xxxx > master volume).
d Select the mono or stereo audio mode (AUDIO xxxx > audio mode > mono or stereo)
e Select the auto follow or breakaway audio mode (AUDIO > audio source > auto follow or input # x):

- auto follow = the audio switching follows automatically the video switching.
- breakaway = the selected audio input is permanently diffused.

f For each audio input, adjust the level (AUDIO xxxx > audio level) and the balance (AUDIO xxxx > audio

balance).

IMPORTANT: If the auxiliary audio input (AUX) is used, don't forget to activate it with the LCD menu (AUDIO

xxxx > AUX input > ON).
