CENTRIX™ & EVENTIX™
APPENDIX A / ANNEXE A
PAGE 127
COMMAND RESPONSE
COMMAND DESCRIPTION
VALUE /VALEUR
COMMANDE RÉPONSE DESCRIPTION DE LA COMMANDE
TYPE
MIN MAX
DESCRIPTION
STATUS COMMANDS / COMMANDES D'ÉTATS
U
UNIT
Measures unity in tens of kHz.
Rd
0 65535 ex: 14500 = 145 MHz
IL ILD
Horizontal period of input signal (M)
Rd
0 65535 Line frequency (in kHz) = (UNIT VALUE)x10
÷ (ILD VALUE).
il ild
Horizontal period of input signal (P)
Rd
0 65535 Line frequency (in kHz) = (UNIT VALUE)x10
÷ (ild VALUE).
ID IFD
Vertical period of input signal (M)
Rd
0 65535 Frame frequency (in Hz) = (Line frequency in
Hz)
÷ (IFD VALUE).
id ifd
Vertical period of input signal (P)
Rd
0 65535 Frame frequency (in Hz) = (Line frequency in
Hz)
÷ (ifd VALUE).
IP IPS
Input Sync. detection (M).
Rd
0
1
0 = no Sync. detected
1 = Sync. detected.
ip ips
Input Sync. detection (P).
Rd
0
1
0 = no Sync. detected
1 = Sync. detected.
IH IHP
Sign of the horizontal input Sync. (M) Rd
0
1
0 = negative
1 = positive.
ih ihp
Sign of the horizontal input Sync. (P)
Rd
0
1
0 = negative
1 = positive.
IV IVP
Sign of the vertical input Sync. (M)
Rd
0
1
0 = negative
1 = positive.
iv ivp
Sign of the vertical input Sync. (P)
Rd
0
1
0 = negative
1 = positive.
IK IST
Input Sync type detection (M).
Rd
0 3
ik ist
Input Sync type detection (P).
Rd
0 3
0 = Separate H &V sync.
1 = Composite sync. (TTL).
2 = SOG (Sync. On Green).
3 = Composite sync. (analog).
II IIN
Interlaced signal detection (M).
Rd
0
1
0 = not interlaced
1 = interlaced.
ii iin
Interlaced signal detection (P).
Rd
0
1
0 = not interlaced
1 = interlaced.
IO IOO
"Out of range" signal detection (M).
Rd
0
1
0 = In range
1 = Out of range.
io ioo
"Out of range" signal detection (P).
Rd
0
1
0 = In range
1 = Out of range.
IF IFA
Standard input signal detection (M).
Rd
0 29
if ifa
Standard input signal detection (P).
Rd
0 29
0 = no signal
15 = SVGA
1 = wrong signal
16 = MAC
2 = NTSC std (3.58/60) 17 = XGA
3 = PAL std (4.43/50) 18 = PLASMA 50'
4 = SECAM (50Hz)
19 = MAC 21'
5 = B&W (50Hz)
20 = SXGA
6 = B&W (60Hz)
21 = UXGA
7 = YUV 50Hz
22 = SXGA+
8 = YUV 60Hz
23 = DILA 4/3
9 = RGB 50Hz
24 = DILA16/9
10 = RGB 60Hz
25 = 1080i 50Hz
11 = VGA1 350L
26 = 1080i 60Hz
12 = VGA2 400L
27 = 480p 60Hz
13 = VGA3 480L
28 = 720p 50Hz
14 = PLASMA 42"
29 = 720p 60Hz
XA REFA
Synchronized input (M).
Rd
0 8
xa refa
Synchronized input (P).
Rd
0 8
Identical as XR command.
XF REFF
Synchronized input standard (M).
Rd
0 29
xf reff
Synchronized input standard (P).
Rd
0 29
Identical as XF command.
XT
REFT
Frame frequency of the synchronized
input (M).
Rd
0 65535 Value in hundredth of Hz.
xt
reft
Frame frequency of the synchronized
input (P).
Rd
0 65535 Value in hundredth of Hz.
OTHERS COMMANDS / COMMANDES DIVERSES
N TBP
T-BAR
position.
Rd/Wr
0
255
ub
TBA
Executed percentage of the effect.
Rd
0 16383 0 = 0%
16383 = 100%
uv TBAV
T-BAR
availability.
Rd
0
1
0 = T-BAR unavailable. 1 = T-BAR available.
? DEV
Device
type.
Rd
0 65535 27 = CTX8022
29 = EVX8022.
#
#1,....#0 Send all device parameters.
Rd
NOTE:
(M) = MAIN output (sortie MAIN).
Rd/Wr = Read and write command / Commande de lecture et d'écriture.
(P) = PREVIEW output (sortie PREVIEW).
Rd = Read only command / Commande de lecture uniquement.
