CENTRIX™ & EVENTIX™ Chapter 6 : EVENTIX™ & REMOTE KEYPAD LCD SCREEN DESCRIPTION (continued)
PAGE 55
6-5. LCD FUNCTIONS DESCRIPTION (continued)
7 [AUDIO MAIN] + ENTER. This menu is available with the OPT-iX-A option only.
The following commands allow controlling the MAIN AUDIO output (OUT 1).
7-1 [master volume] + ENTER.
Adjust the audio output level with  + ENTER.
7-2 [audio mode] + ENTER.
Select the output audio mode with  + ENTER.
• [mono]: Set the output in mono mode.
• [stereo]: Set the output in stereo mode.
7-3 [audio source] + ENTER.
Select an item with  + ENTER:
• [auto follow]: The audio follows the video image.
• [input --]: The selected audio input (is permanently diffused).
7-4 [audio level] + ENTER.
This function allows to separately adjusting the level of each audio input. Adjust the level with  + ENTER.
NOTE: This function acts on the selected (diffused) audio input.
7-5 [audio balance] + ENTER.
This function allows adjusting for each input the audio balance. Adjust the level with  + ENTER.
NOTE: This function acts on the selected (diffused) audio input.
7-6 [AUX input] + ENTER.
Auxiliary input for mixing with the diffused source.
7-7 [mute off] + ENTER.
Switch ON or OFF the audio output. Validate with ENTER.
8
[AUDIO PRELIST] + ENTER. This menu is available with the OPT-iX-A option only.
The following commands allow controlling the PRELIST AUDIO output (OUT 2).
8-1 [master volume] + ENTER.
Adjust the audio output level with  + ENTER.
8-2 [audio mode] + ENTER.
Select the output audio mode with  + ENTER.
• [mono]: Set the output in mono mode.
• [stereo]: Set the output in stereo mode.
8-3 [audio source] + ENTER.
Select an item with  + ENTER:
• [auto follow]: The audio follows the video image.
• [input --]: The selected audio input (is permanently diffused).
8-4 [audio level] + ENTER.
This function allows to separately adjusting the level of each audio input. Adjust the level with  + ENTER.
NOTE: This function acts on the selected (diffused) audio input.
8-5 [audio balance] + ENTER.
This function allows adjusting for each input the audio balance. Adjust the level with  + ENTER.
NOTE: This function acts on the selected (diffused) audio input.
8-6 [AUX input] + ENTER.
Auxiliary input for mixing with the diffused source.
8-7 [mute off] + ENTER.
Switch ON or OFF the audio output. Validate with ENTER.
