CENTRIX™ & EVENTIX™
APPENDIX A / ANNEXE A
PAGE 121
A-4: COMMANDS AND RESPONSES TABLE
A-4: TABLE DES COMMANDES ET RÉPONSES
COMMAND RESPONSE
COMMAND DESCRIPTION
VALUE /VALEUR
COMMANDE RÉPONSE DESCRIPTION DE LA COMMANDE
TYPE
MIN MAX
DESCRIPTION
SELECTION COMMANDS / COMMANDES DE SÉLECTION
MM
MTRX
Switching mode selection.
Rd/Wr
0
1
0 = mixer mode
1 = matrix mode
CC
CH
MAIN selected input.
Rd
0 8
CN CHN
• Background switching during a PIP
(in MIXER mode).
• Input pre-selection for OUTPUT 1
(in MATRIX mode).
Rd/Wr
0 8
cc
ch
PREVIEW selected input (read only). Rd
0 8
cn chn
• Input pre-selection & PIP switching
(in MIXER mode).
• Input pre-selection for OUTPUT 2
(in MATRIX mode).
Rd/Wr
0 8
0 = black
1 = input #1
2 = input #2
3 = input #3
4 = input #4
5 = input #5
6 = input #6
7 = input #7
8 = input #8
G TAKE
TAKE
(transition).
Rd/Wr
0
1
1 = start the transition (automatic reset at the
end of the effect duration).
0 = stop the transition (for holding effect).
ut TKEV
Transition
availability.
Rd
0
1
1 = New input ready to commute.
Z
FRZ
FREEZE MAIN.
Rd/Wr
0
1
0 = inactive
1 = active.
z
frz
FREEZE PREVIEW.
Rd/Wr
0
1
0 = inactive
1 = active.
INPUT COMMANDS / COMMANDES D'ENTRÉE
PC
PCH
Input selection for adjustment.
Rd/Wr
0
8
0 = all inputs.
1 = input #1.... 8 = input #8
PE
PEN
Input disabling (works with PC)
Rd/Wr
0
1
0 = disable
1 = enable.
PL
PLD
H sync load selection (works with PC). Rd/Wr
0
1
0 = Hi-Z load
1 = 75Ω load.
PR PRGB
RGB input type selection (works with
PC command).
Rd/Wr
0 10
0 = composite
1 = S.VIDEO
2 = YUV
3 = RGBS (TTL)
4 = RGsB (SOG)
5 = RGBS (ana)
6 = SDI.
7 = computer (SOG)
8 = comp (HV or C.) 9 = comp DVI
10 = HDTV.
PI PSTD
Input standard selection (works with
PC command).
Rd/Wr
0 4
0 = NTSC/PAL/SECAM.
1 = NTSC.
2 = PAL.
3 = SECAM
4 = Black & White.
PP
PPRC
VCR mode
Rd/Wr
0
1
0 = OFF
1 = ON.
OUTPUT COMMANDS / COMMANDES DE SORTIE
FM OFTM
Output formats selection (M).
Rd/Wr
0 20
fp oftp
Output formats selection (P).
Rd/Wr
0 20
0 = SVGA 50Hz
1 = SVGA 60Hz
2 = SVGA 72Hz
3 = SVGA 75Hz
4 = XGA 50Hz
5 = XGA 60Hz
6 = XGA 72Hz
7 = XGA 75Hz
8 = SXGA 50Hz
9 = SXGA 60Hz
10 = SXGA 72Hz
11 = SXGA 75Hz
12 = SXGA+ 50Hz
13 = SXGA+ 60Hz
14 = SXGA+ 72Hz
15 = SXGA+ 75Hz
16 = D-ILA 4/3 75Hz 17 = D-ILA 16/9 75 Hz
18 = WVGA 16/9 60 19 = HDTV 720p 50Hz
20 = HDTV 720p 60Hz
FY OSYN
Output sync selection (M).
Rd/Wr
0 2
fy osyn
Output sync selection (P).
Rd/Wr
0 2
0 = H &V sync.
1 = Composite sync.
2 = SOG
FS SCRM
Type of screen selection (M)
Rd/Wr
0
1
0 = 4/3 screen
1 = 16/9 screen
fs scrp
Type of screen selection (P)
Rd/Wr
0
1
0 = 4/3 screen
1 = 16/9 screen
pm PAT
Test pattern selection (M).
Rd/Wr
0 7
pp pat
Test pattern selection (P).
Rd/Wr
0 7
0 = no pattern 1 = centering 2 = color
3 = grey scale 4 = grid.
5 = softedge
6 = multi-burst. 7 = H grey scale
XR REFR
Output rate selection (Mixer mode).
Output 1 rate selection (Matrix mode)
Rd/Wr
0 8
xr
refr
Output 2 rate selection (Matrix mode). Rd/Wr
0
8
0 = internal rate
1 = follow input #1
2 = follow input #2... 8 = follow input #8
NOTE:
(M) = MAIN output (sortie MAIN).
Rd/Wr = Read and write command / Commande de lecture et d'écriture.
(P) = PREVIEW output (sortie PREVIEW).
Rd = Read only command / Commande de lecture uniquement.
