27
Fonction
s de
contournage
Trajectoire circulaire CR avec indication du rayon
Coordonnées du point final de l'arc de cercle
Rayon R
Grand arc de cercle: ZW > 180, R négatif
Petit arc de cercle: ZW < 180, R positif
Sens de rotation DR
ou
ou
ou
10 L X+40 Y+40 RL F200 M3
11 CR X+70 Y+40 R+20 DR- (ARC 1)
11 CR X+70 Y+40 R+20 DR+ (ARC 2)
10 L X+40 Y+40 RL F200 M3
11 CR X+70 Y+40 R-20 DR- (ARC 3)
11 CR X+70 Y+40 R-20 DR+ (ARC 4)
X
Y
ZW
R
R
40
40
70
1
2
DR+
DR
X
Y
40
40
70
DR+
4
ZW
3
R
R
DR
