APPENDIX A / ANNEXE A
OCTO VUE / QUATTRO VUE
PAGE 96
COMMAND RESPONSE
COMMAND DESCRIPTION
VALUE /VALEUR
COMMANDE RÉPONSE
DESCRIPTION DE LA COMMANDE
TYPE
MIN MAX
DESCRIPTION
STATUS COMMANDS / COMMANDES D'ÉTAT
UN
UN
Measures unity in tens of kHz.
Rd
0 65535 ex: 14500 = 145 MHz
IL
IL
Horizontal period of input signal (M)
Rd
0 65535 Line frequency (in kHz) = (UN VALUE)x10
÷
(IL VALUE).
il
il
Horizontal period of input signal (P)
Rd
0 65535 Line frequency (in kHz) = (UN VALUE)x10
÷
(il VALUE).
ID
ID
Vertical period of input signal (M)
Rd
0 65535 Frame frequency (in Hz) = (Line frequency in
Hz)
÷ (ID VALUE).
id
id
Vertical period of input signal (P)
Rd
0 65535 Frame frequency (in Hz) = (Line frequency in
Hz)
÷ (id VALUE).
IP
IP
Input Sync. detection (M).
Rd
0
1
0 = no Sync. detected
1 = Sync. detected.
ip
ip
Input Sync. detection (P).
Rd
0
1
0 = no Sync. detected
1 = Sync. detected.
IH
IH
Sign of the horizontal input Sync. (M) Rd
0
1
0 = negative
1 = positive.
ih
ih
Sign of the horizontal input Sync. (P)
Rd
0
1
0 = negative
1 = positive.
IV
IV
Sign of the vertical input Sync. (M)
Rd
0
1
0 = negative
1 = positive.
iv
iv
Sign of the vertical input Sync. (P)
Rd
0
1
0 = negative
1 = positive.
IK
IK
Input Sync type detection (M).
Rd
0 3
ik
ik
Input Sync type detection (P).
Rd
0 3
0 = Separate H &V sync.
1 = Composite sync. (TTL).
2 = SOG (Sync. On Green).
3 = Composite sync. (analog).
II
II
Interlaced signal detection (M).
Rd
0
1
0 = not interlaced
1 = interlaced.
ii
ii
Interlaced signal detection (P).
Rd
0
1
0 = not interlaced
1 = interlaced.
IO
IO
"Out of range" signal detection (M).
Rd
0
1
0 = In range
1 = Out of range.
io
io
"Out of range" signal detection (P).
Rd
0
1
0 = In range
1 = Out of range.
IF
IF
Standard input signal detection (M).
Rd
0 35
if
if
Standard input signal detection (P).
Rd
0 35
0 = no signal
1 = wrong signal
2 = NTSC std (3.58/60) 3 = PAL std (4.43/50)
4 = SECAM (50Hz)
5 = B&W (50Hz)
6 = B&W (60Hz)
7 = YUV 50Hz
8 = YUV 60Hz
9 = RGB 50Hz
10 = RGB 60Hz
11 = 640x480
12 = 800x600
13 = 1024x768
14 = 1280x1024
15 = 1400x1050
16 = 1600x1200
17 = 852x480
18 = 1280x720
19 = 1280x768
20 = 1366x768
21 = 1680x1050
22 = 1920x1080
23 = 1080i 50
24 = 1080i60
25 = 720p 50
26 = 720p 60
26 = 1080p 24
28 = 1080p 25
29 = 1080p 30
30 = 1080p 50
31 = 1080p 60
32 = 1080sf 24
33 = 480p 50
34 = 480p 60
35 = 480p 72
XA XA
Synchronized
input.
Rd
0 8
Identical as XR command.
XF
XF
Synchronized input standard (M).
Rd
0 29
Identical as IF command.
XT
REFT
Frame frequency of the synchronized
input (M).
Rd
0 65535 Value in hundredth of Hz.
OTHERS COMMANDS / COMMANDES DIVERSES
TP TP
T-BAR
position.
Rd/Wr
0
255
TB
TB
Executed percentage of the effect.
Rd
0 65535 0 = 0%
65535 = 100%
? DEV
Device
type.
Rd
0 65535
# #1,....#0
Send
all
device parameters.
Rd
NOTE:
(M) = MAIN output (sortie MAIN).
Rd/Wr = Read and write command / Commande de lecture et d'écriture.
(P) = PREVIEW output (sortie PREVIEW).
Rd = Read only command / Commande de lecture uniquement.
