OCTO VUE / QUATTRO VUE Chapter 4 : USING FRAME STORE AND LOGO INSERTION
PAGE 25
4-2. USING THE FRAME STORE
This function allows memorizing up to 4 frames (images) in order to display it at any time during the show.
IMPORTANT: The output format used when displaying the frame should be the same that the output format used during
the FRAME storing.
• HOW TO STORE A FRAME:
Select the source of the frame to be stored (with the INPUT SELECTION buttons).
Select the record frame mode (LOGOS/FRAME > record frame): the device displays a white rectangle
corresponding to the frame selection area onto the output. If necessary adjust the position and size of the frame
selection area (IMAGE > pos settings).
Store the frame (LOGOS/FRAME > record frame > store). The memorization starts and will take about 2
minutes.
NOTE: For motion picture, you can use the FREEZE function, before doing the memorization.
• HOW TO DISPLAY ON or OFF the FRAME:
To display ON the FRAME, select a Frame selection button of the front panel (Fn then F1, F2, F3 or F4) then press
TAKE.
To display OFF the FRAME, select an input selection button, then press TAKE.
