OCTO VUE / QUATTRO VUE
Chapter 5 : FRONT PANEL DISPLAY MENUS DESCRIPTION (continued)
PAGE 33
5
[LOGOS/FRAME*] + ENTER
5-1 [Use logo] + ENTER.
Select an item with
+ ENTER.
5-1-1 [Display] + ENTER.
This function allows displaying ON or OFF the assigned logos of each input. Select an input with
and
press ENTER to display ON or OFF.
NOTE: To display a logo the output format should be the same that the output format used during the
storing.
5-1-2 [Assignment] + ENTER.
This function allows assigning the stored logos to the inputs device (up to 2 logos at the same time).
Select an input with
+ ENTER.
Select the INDEX 1 or the INDEX 2 with
+ ENTER.
Then select a logo or none with
+ ENTER.
5-1-3 [Position] + ENTER.
Adjust the logo position with H& V position functions.
5-1-4 [Transparency] + ENTER.
This function allows to adjust the logo transparency.
5-1-5 [Fade duration] + ENTER.
This function allows adjusting the fade duration of the logo when you display ON or OFF a logo. Adjust
the duration with
and validate with ENTER.
5-2 [Record
logo]
+
ENTER.
This mode allows storing up to 8 logos in order to incrust them into the displayed image (up to 2 logos at a same
time). Select an item with
+ ENTER.
5-2-1 [H position] + ENTER.
Adjust the Horizontal position of the logo area with
+ ENTER.
5-2-2 [V position] + ENTER.
Adjust the Vertical position of the logo area with
+ ENTER.
5-2-3 [H size] + ENTER.
Adjust the Horizontal size of the logo area with
+ ENTER.
5-2-4 [V size] + ENTER.
Adjust the Vertical size of the logo area with
+ ENTER.
NOTE: The logo area is limited at an eighth (1/8) of the displayed area.
5-2-5 [Luma key level] + ENTER.
This function allows to “erase” the darkest portions of your logo area in order to make special logo contour.
Adjust the luma key level with
+ ENTER.
5-2-6 [Back. Color] + ENTER.
This function allows coloring the “erased portions” of the logo when using the luma key. Select a level with
+ ENTER.
5-2-7 [Store] + ENTER.
This function allows storing the logo into one of the 8 memories. Select a logo memory with
+
ENTER.
The memorization will take few seconds.
