APPENDIX A / ANNEXE A OCTO VUE / QUATTRO VUE
PAGE 94
COMMAND RESPONSE
COMMAND DESCRIPTION VALUE /VALEUR
COMMANDE RÉPONSE DESCRIPTION DE LA COMMANDE
TYPE
MIN MAX DESCRIPTION
FRAME & LOGOS COMMANDS (continued)/ COMMANDES DU MENU LOGO & FRAME (suite)
lH lH Horizontal position of the logo 1 (P). Rd/Wr 0 255
lV lV Vertical position of the logo 1 (P). Rd/Wr 0 255
lW lW Logo 1 horiz. size % output format (P). Rd 5 255 5 = 3% 255 = 100%
lS lS Logo 1 vert. size % output format (P). Rd 5 255 5 = 3% 255 = 100%
lT lT Logo 1 type (P). Rd 0 2
0 = incrusting logo
1 = cutting logo
2 = animating logo
lP lP Pixels number in a line of the logo 1 (P). Rd 0 65535
lL lL Lines number in a logo 2 (P). Rd 0 65535
These 2 commands allow calculating the
duration of the storing.
lh lh Horizontal position of the logo 2 (P). Rd/Wr 0 255
lv lv Vertical position of the logo 2 (P). Rd/Wr 0 255
lw lw Logo 2 horiz. size % output format (P). Rd 5 255 5 = 3% 255 = 100%
ls ls Logo 2 vert. size % output format (P). Rd 5 255 5 = 3% 255 = 100%
lt lt Logo 2 type (P). Rd 0 2
0 = incrusting logo
1 = cutting logo
2 = animating logo
lp lp Pixels number in a line of the logo 2 (P). Rd 0 65535
ll ll Lines number in a logo 2 (P). Rd 0 65535
These 2 commands allow calculating the
duration of the storing.
lN lN Pixels number in a line of the frame (P). Rd 0 65535
ln ln Line number of the frame (P) Rd 0 65535
lE lE Status of the logo memories Rd 0 1 0 = logo memorized. 1 = empty memory.
lF lF Status of the logo memories Rd 0 1 0 = logo memorized. 1 = empty memory.
LE LE Luma key level. Rd/Wr 0 255
Lb Lb Background color. Rd/Wr 0 7
LR LR
-In recording mode: frame/logo storing.
-In erase mode: frame/logo erasing.
Rd 0 1
1 = STORE (automatic reset).
1 = ERASE (automatic reset).
Lr Lr Stop the frame storing. Rd/Wr 0 1 1 = stop the frame storing (automatic reset).
LZ LZ Logo transparency Rd/Wr 0 15 0 = mini 15 = maxi
Ld Ld Fade logo duration (0.01 second step). Rd/Wr 15 255 15 = 0.15 second 255 = 2.5 seconds
Lf Lf Fade frame duration (0.1 second step). Rd/Wr 5 50 5 = 0.1 second 50 = 5 seconds
NOTE: To store a logo from the MAIN display you should:
Select the logo recording mode with the LM command (1LM).
Adjust the position and size of the logo storing area with the LU, Lu, LW and LS commands.
Adjust the luma key level (with LE command) and the background color (with Lb command).
Select a logo memory with the LC command and do a store with LR command (1LR).
To store a frame from the MAIN display you should:
Select the frame recording mode with the LM command (3LM), and do a store with the LR command (1LR).
NOTE: To assign a logo/frame to an input on the MAIN display you should:
Select the assignment mode with the LM command (0LM).
Select the input with the PC command.
Select a stored logo/frame with LA, LB or LF commands.
Adjust the horizontal & vertical position of the logo with the LH, Lh, LV & Lv commands.
NOTE: (M) = MAIN output (sortie MAIN). Rd/Wr = Read and write command / Commande de lecture et d'écriture.
(P) = PREVIEW output (sortie PREVIEW). Rd = Read only command / Commande de lecture uniquement.
