OCTO VUE / QUATTRO VUE Chapter 5 : FRONT PANEL DISPLAY MENUS DESCRIPTION (continued)
PAGE 29
5-5. FUNCTIONS DESCRIPTION
1 [SWITCHING] + ENTER.
1-1 [Fast switching] + ENTER.
Select an item with + ENTER.
• [Internal rate]: The output frame rate is 60 Hz or 75 Hz depending of the selected output format. A higher
frame frequency gives a better visual aspect when displaying static pictures.
• [Follow # x]: The output frame rate is identical to the selected input Frame Rate: 50 Hz if the input video
standard is PAL or SECAM and 59.94 Hz if the input video standard is NTSC. This function
allows improving the motion pictures.
1-2 [seamless] + ENTER.
Select the computer input take as reference with + ENTER.
• [Seamless #1]: The device is in Seamless mode. The output format & rate are the same as computer #1.
• [Seamless #8]: The device is in Seamless mode. The output format & rate are the same as computer #8.
2
[INPUT] + ENTER.
2-1 [Auto settings] + ENTER.
This function detects automatically the input type of each source connected to the inputs.
2-2 [Input status] + ENTER.
Indicates the status of the selected input.
2-3 [Input type] + ENTER.
Select an input with + ENTER.
Select the input signal type with + ENTER between:
• [SDTV Composite] • [SDTV RGB SOG]
• [SDTV S.VIDEO] • [SDTV RGBS ana.]
• [SDTV YUV] • [Computer SOG]
• [SDTV RGBS TTL] • [Computer HV/C]
• [Computer DVI]
• [HDTV]: HDTV input format (720p, 1035i and 1080i).
• [Audio only]: Select this function if you only want to connect an audio source (no video signal needed).
Then for [SDTV Composite], and [SDTV S.VIDEO], select the video standard with + ENTER between:
• [NTSC / PAL / SECAM]: automatic NTSC, PAL, and SECAM standard detection.
• [NTSC]: NTSC standard detection only. • [PAL]: PAL standard detection only.
• [NTSC 4.43 60 Hz]: NTSC 4.43 60Hz detection. • [PAL 4.43 60Hz]: PAL 4.43 60Hz detection.
• [SECAM]: SECAM standard detection only. • [B & W 50/60 Hz]: Black and White detection.
2-4 [used input] + ENTER.
Select an input and then select an item + ENTER between:
• [used]: A signal is connected to the input.
• [unused]: No signal is connected to the input. The input is unused.
2-5 [H sync load] + ENTER.
Select for each input the load of the H Sync. with + ENTER.
2-6 [VCR mode] + ENTER.
This function allows improving the image contour of low quality VHS tapes. Select [on] with ENTER.
2-7 [VIS] + ENTER.
This function allows defining the sources which are synchronized together (external genlock). The synchronized
sources can be seamless switched between themselves during an effect (into a PIP for example). This switching
mode is called VIS (Vertical Interval Switching).
