Chapter 5 : FRONT PANEL DISPLAY MENUS DESCRIPTION (continued)
OCTO VUE / QUATTRO VUE
PAGE 34
5-3 [Record anim] + ENTER.
This mode allows storing an animated logo in order to incrust them into the displayed image Select an item with
+ ENTER.
5-3-1 [H position] + ENTER.
Adjust the Horizontal position of the logo area with
+ ENTER.
5-3-2 [V position] + ENTER.
Adjust the Vertical position of the logo area with
+ ENTER.
5-3-3 [H size] + ENTER.
Adjust the Horizontal size of the logo area with
+ ENTER.
5-3-4 [V size] + ENTER.
Adjust the Vertical size of the logo area with
+ ENTER.
NOTE: The logo area is limited at an eighth (1/8) of the displayed area.
5-3-5 [Luma key level] + ENTER.
This function allows to “erase” the darkest portions of your logo area in order to make special logo contour.
Adjust the luma key level with
+ ENTER.
5-3-6 [Back. Color] + ENTER.
This function allows coloring the “erased portions” of the logo when using the luma key. Select a level with
+ ENTER.
5-3-7 [Recording time] + ENTER.
Adjust the recording time with
+ ENTER.
5-3-8 [Store] + ENTER.
This function allows storing the logo into the memory. The memorization will take few seconds.
5-4 [Record frame] + ENTER.
This mode allows storing up to 4 frames in order to display them at any time during the show.
5-4-1 [H position] + ENTER.
Adjust the Horizontal position of the frame area with
+ ENTER.
5-4-2 [V position] + ENTER.
Adjust the Vertical position of the frame area with
+ ENTER.
5-4-3 [H size] + ENTER.
Adjust the Horizontal size of the frame area with
+ ENTER.
5-4-4 [V size] + ENTER.
Adjust the Vertical size of the frame area with
+ ENTER.
5-4-5 [Luma key level] + ENTER.
This function allows to “erase” the darkest portions of your frame in order to make special frame contour.
Adjust the luma key level with
+ ENTER.
5-4-6 [Store]
This function allows storing the displayed image (frame) into a one of the 4 memories. Presses ENTER to
start the memorization of the frame. The memorization will take about 2 minutes.
5-5 [Erase logo] + ENTER.
This function allows erasing the memorized logos. Select an item with
+ ENTER.
5-6 [Erase frame] + ENTER.
This function allows erasing the memorized frames. Select an item with
+ ENTER.
