OCTO VUE / QUATTRO VUE
PAGE 8
OCTO VUE TM / QUATTRO VUE TM
Chapter 1 : INTRODUCTION
1-1. ACCESSORIES SUPPLIED
• 1 OCTO VUE FX (OVX831) or 1 OCTO VUE FADE (OVF831) or 1 OCTO VUE (OVP831) or 1 QUATTRO VUE
(QVP421) or 1 QUATTRO VUE FX (QVX421)
• 1 AC Power supply cord.
• 1 HD15 male / 5Xbnc female cable adaptor.
• 1 HD15 female / DVI-I male adaptor.
• 1 Set of 5 MCO (5-pin) female connectors (OVX831, OVF831, OVP831).
• 1 Set of 3 MCO (5-pin) female connectors (QVP421, QVX421).
• 1 CD-ROM (Remote Control Software).
• 1 User’s Manual.
1-2. OCTO VUE GENERAL INFORMATION
The OCTO VUE (FADE / FX) by Analog Way is High Resolution Digital and Analog Computer & Video Up/Down
Scaler Switcher. In addition, the device offers a true scaled preview and many effects including High Resolution PIP in
Computer & Video formats.
It features many other effects: fading* & titling*, Hi-Res. Logo insertion and frame store. It is fitted with 8 Universal
A/V inputs including one DVI, and 4 outputs: 2 Analog and 1 DVI for the Main; 1 Analog for the Preview. It performs
an ultra fast and smooth transition between any Video or Computer sources. It also allows a true seamless switching
between one computer Input (direct) and any other Video or Computer Input.
Preview: The device is fitted with a true scaled Preview out offering the facility to visualize any source before
displaying it on the Main output. Preview out ensures easy and safe presentations since any Video or Computer source
can be checked on a simple LCD screen before being displayed to the audience.
PIP: The device creates High quality picture insertion from any input. The PIP can be sized and moved anywhere over
the background image. Background image can be switched between one Computer source and Frame. The PIP source
can be fast & smoothly switched through a fade to black or customized color. The PIP opening offers a choice between
Cut and Fade.
Title Effect*: The device can mix a Computer source with a Title with any Video or Computer source. The title remains
on the screen during the transition. The device also features a shadow title effect with settable vertical size and position
that enhances the readability of the titling text over very bright images.
Fade Effect*: The device features cross-fade effects between Computer and Video (TV/HDTV) or Computer sources,
with adjustment of the cross-fading duration.
Logos and Frames**: The device can store in its non volatile memory 8 Still and 1 Animated Logos and 4 Full Frame
Images in true Hi-Res. 16 million colors. Recording is done either by direct acquisition from Input source or from
Computer download of image files. Up to 2 Logos can be assigned to each input to be displayed at any position on the
output screen.
Logos can have any shape due to the keying capability, and transparency is user adjusted. Full Frames can be used as
welcome or transition image or PIP Background.
The device is a High Performance State of the Art Up/Down Video and Computer Scaler. Ready to fit the native
resolution of the latest HD display devices, it provides a high quality image thanks to its high quality digital decoder,
improved 3:2 and 2:2 pull down circuitry, auto-adaptative pixel by pixel 3D motion compensation, time base corrector,
frame rate converter & follower.
Easy to use, the device offers Auto Setup function, Auto Clock and Phase for Computers. Each input image control –
brightness, contrast, color, hue, processing, aspect ratio, zoom, etc … - can be individually set and stored in nonvolatile
memories. Each of the 8 Inputs is fitted with a stereo audio line. The audio can either follow or break away from the
Video image. One additional audio stereo input is provided to be mixed with the Video input audio line. The device is
fitted with a Dual RS232 Com port for Integral remote control and automatic control of other devices in the installation.
Full Firmware upgrade maintains high value to your equipment through permanent additional possibility in the
apparatus life time. Upgrades are available on Analog Way web site. An optional TCP/IP connection allows far away
remote and/or upgrade.
This ultra compact and user friendly device is especially dedicated to high resolution A/V presentation displays,
conference and boardrooms, and events.
* OVX831 & OVF831.
** OVX831 only.
