APPENDIX A / ANNEXE A
OCTO VUE / QUATTRO VUE
PAGE 92
COMMAND RESPONSE
COMMAND DESCRIPTION
VALUE /VALEUR
COMMANDE RÉPONSE
DESCRIPTION DE LA COMMANDE
TYPE
MIN MAX
DESCRIPTION
EFFECTS COMMANDS / COMMANDES D'EFFET
EF
EF
Effect selection.
Rd/Wr
0
4
0 = CUT.
1 = FADING.
2 = TITLE.
4 =
PIP.
ED
ED
Effect duration selection.
Rd/Wr
5
255 5 = 0.5 second
244 = 24.5 seconds
255 = holding
ea
ea
Horizontal position of the effect.
Rd/Wr
0
255
eb
eb
Vertical
position
of the effect
Rd/Wr
0
255
ec
ec
Horizontal size of the effect
Rd/Wr
0
255 0 = PIP 1:1
5 = size mini 255 = size maxi
ed
ed
Vertical size of the effect.
Rd/Wr
0
255 0 = PIP 1:1
5 = size mini 255 = size maxi
ee
ee
Window horizontal position (PIP).
Rd/Wr
0
255
ef
ef
Window vertical position (PIP).
Rd/Wr
0
255
eg
eg
Window horizontal size (PIP).
Rd/Wr
0
255
eh
eh
Window
vertical
size (PIP).
Rd/Wr
0
255
eO
eO
Effect
options
Rd/Wr
0
5
0 = without
1 = shadow
2 = smooth
3 = edge
ei
ei
Effect options parameters (size,
shadow...).
Rd/Wr
0 255
0 = size mini
255 = size maxi.
ej
ej
Effect options parameters (color).
Rd/Wr
0 255
EO
EO
Effect opening type.
Rd/Wr
0
1
0 = Cut
1 = fade
EC
EC
Effect closing type.
Rd/Wr
0
1
0 = Cut
1 = fade
Eo
Eo
Effect opening duration (0.1 sec step)
Rd/Wr
0 255
Ec
Ec
Effect closing duration (0.1 sec step)
Rd/Wr
0 255
TO
TO
Effect in progress.
Rd
0
1
0 = no effect in progress.
1 = effect in progress.
AUDIO COMMANDS / COMMANDES AUDIO
AC
AC
Audio source selection of the MAIN.
Rd/Wr
1
8
1 = audio source #1.... 8 = audio source #8.
ac ac
Audio source selection of the PRELIST
output.
Rd/Wr
1
8
1 = audio source #1.... 8 = audio source #8.
AO
AO
Audio mode of the MAIN output.
Rd/Wr
0
1
0 = auto follow
1 = breakaway
ao
ao
Audio mode of the PRELIST output.
Rd/Wr
0
1
0 = auto follow
1 = breakaway
AV
AV
Mater volume of the MAIN output.
Rd/Wr
0
255
av
av
Mater volume of the PRELIST output. Rd/Wr
0
255
AT
AT
Mute of the MAIN output.
Rd/Wr
0
1
0 = mute OFF
1 = mute ON
at
at
Mute of the PRELIST output
Rd/Wr
0
1
0 = mute OFF
1 = mute ON
AS
AS
Mono/stereo mode of the MAIN output. Rd/Wr
0
1
0 = stereo
1 = mono
as
as
Mono/stereo mode of the PRELIST.
Rd/Wr
0
1
0 = stereo
1 = mono
AL
AL
Audio level (works with PC command) Rd/Wr
0
64 0 = minimum
1 = maximum
AB
AB
Audio balance (works with PC)
Rd/Wr
0
64 0 = left to maximum 64 = right to maximum
AX
AXMU
Auxiliary source to MAIN.
Rd/Wr
0
1
0 = used
1= unused.
ax
axmu
Auxiliary source to PRELIST.
Rd/Wr
0
1
0 = used
1= unused.
NOTE:
(M) = MAIN output (sortie MAIN).
Rd/Wr = Read and write command / Commande de lecture et d'écriture.
(P) = PREVIEW output (sortie PREVIEW).
Rd = Read only command / Commande de lecture uniquement.
