Chapter 1 : INTRODUCTION (continued) OCTO VUE / QUATTRO VUE
PAGE 10
1-4. DEVICES & OPTIONS REFERENCES
REFERENCE DESIGNATION
OVX831 OCTO VUE FX.
OVF831 OCTO VUE FADE
OVP831 OCTO VUE.
QVP421 QUATTRO VUE
QVX421 QUATTRO VUE FX
OPT-LAN LAN communication port (optional).
1-5. INSTALLATION
IMPORTANT: Please read all the safety instructions (pages 3 to 5) before starting.
• Table Top Mounting: The device can be used directly on a table: the unit is equipped with 4 plastic feet.
• Rack Mounting:
The device is compatible with a 19” enclosure. To install the device into a 19” rack: Attach the
device to the rack by using 4 screws in the front panel holes (screws are not included).
IMPORTANT:
• The openings in the rear and side panels are for cooling. Do not cover these openings.
• Be sure that no weight is added to the device in excess of 2 kg (4.4 lbs.).
• The maximum ambient operating temperature must not exceed 40°C (104°F).
• The rack and all mounted equipment in it must be reliably grounded to national and
local electrical codes.
