OCTO VUE / QUATTRO VUE Chapter 8 : TECHNICAL SPECIFICATIONS (continued)
PAGE 45
8-1. COMPUTER & VIDEO INPUTS (continued)
• S.VIDEO
Connectors: 4-pin mini DIN (input #8*), BNC (input #7* or input #4**), HD15 (inputs #2 to 8) and
DVI-I (input #1).
Standards:
PAL (15.625 kHz / 50 Hz – 625 lines) or NTSC (15.734 kHz / 60 Hz – 525 lines).
Levels :
Y = 1 Vp/p.
C = 0.3 Vp/p.
Impedance: 75 ohms.
• COMPOSITE VIDEO
Connectors:
BNC (input #7* or input #4**), RCA (input #8*), HD15 (inputs #2 to 8) and DVI-I (input #1).
Standards:
PAL / SECAM (15.625 kHz / 50 Hz – 625 lines) or NTSC (15.734 kHz / 60 Hz – 525 lines).
Level: 1
Vp/p.
Impedance: 75
ohms.
8-2. DISPLAY OUTPUTS
• MAIN ANALOG
Connectors: HD15 and DVI-I* (2 x buffered).
Resolution: 4/3 & 5/4: 800x600, 1024x768, 1280x1024, 1400x1050, 1600x1200.
16/9 & 16/10: 852x480, 1280x720, 1280x768, 1366x768, 1920x1080.
Frame frequency:
50, 60, 72***, 75*** Hz and follow (*** = not available for all resolutions).
Sync. types:
RGBHV, RGB/S, RGsB (Sync On Green).
Levels:
R, G, B = 0.7 Vp/p.
H & V Sync = TTL
Composite Sync = TTL and 0.3 V.
SOG (Sync On Green) = 0.3 V.
Impedance: R, G, B = 75 ohms.
• MAIN DIGITAL
Connector: DVI-I.
Format: Digital Visual Interface (DVI). TMDS Single link.
Resolution: Up to 1600 x 1200 @ 60 Hz.
• PREVIEW
Connectors: HD15.
Format: XGA / 60 Hz.
Sync. types: RGBHV.
Levels: R, G, B = 0.7 Vp/p.
H & V Sync = TTL
Impedance: R, G, B = 75 ohms.
8-3. AUDIO INPUTS
Connectors: Jack 3.5 mm (inputs #1, 2* & 8*) and MCO (inputs #2**, 3, 4, 5*, 6*, 7* & AUX*).
Type: Stereo balanced (inputs 7* & AUX*) & unbalanced (all).
Levels:
Vi = + 18 dBu (max).
Zi = 20 kΩ unbalanced.
Zi = 40 kΩ balanced.
Gain: Adjustable.
* OVX831, OVF831 & OVP831. ** QVP421 & QVX421.
