Chapter 5 : FRONT PANEL DISPLAY MENUS DESCRIPTION (continued)
OCTO VUE / QUATTRO VUE
PAGE 32
• If the selected input type is a COMPUTER signal the IMAGE MENU displays:
4-1 [Centering]
+
ENTER.
Adjust automatically the image in the centering pattern.
4-2 [Pos.
settings]
+
ENTER.
Select one of the following functions with
+ ENTER.
4-2-1 [H position] + ENTER.
Adjust the Horizontal position with
+ ENTER.
4-2-2 [V position] + ENTER.
Adjust the Vertical position with
+ ENTER.
4-2-3 [H size] + ENTER.
Adjust the Horizontal size with
+ ENTER.
4-2-4 [V size] + ENTER.
Adjust the Vertical size with
+ ENTER.
4-3 [Aspect in] + ENTER.
Select the Aspect Ratio of your input source with
+ ENTER.
• [4/3 standard]: 4/3 input format.
• [16/9 letterbox]: Letterbox input format.
• [WS anamorphic]: Widescreen Anamorphic input format (video) or 16/9 input format (computer).
4-4 [Aspect
out]
+
ENTER.
Select one of the following output aspect ratio with
+ ENTER.
• [Standard]: The entire image and the aspect ratio are preserved.
• [Crop]:
The image is zoomed without deformation to fill the screen, but some borders of the image will
be cropped. The aspect ratio is preserved.
• [Full Screen]: The image is stretched to fill the screen. The aspect ratio is not preserved.
• [Zoom]:
The image can be zoomed, cropped and stretched at your convenience.
4-5 [Black level] + ENTER.
Adjust the black level with
+ ENTER.
4-6 [Color]
+
ENTER.
Select a color (Red, Green, or Bleu) with
+ ENTER and adjust the level with
+ ENTER.
4-7 [Optimize]
+
ENTER.
Select an item with
+ ENTER.
• [clock]: Manual adjustment of the pixel clock.
• [phase]: Manual adjustment of the pixel phase.
4-8 [Preset]
+
ENTER.
This function allows setting all the image parameters to the factory settings. Select [YES] and validate with
ENTER.
NOTE: If the selected input is the reference computer input, the available adjustments are: Black level & Color.
