OCTO VUE / QUATTRO VUE Chapter 5 : FRONT PANEL DISPLAY MENUS DESCRIPTION (continued)
PAGE 35
6 [EFFECT]
This menu allows to store an effect in each of the effect buttons (EFFECT PRESET).
First select an effect button with LCD menu or with the front panel button.
Then select one of the following effects:
6-x-1 [Cut]: allows switching seamlessly the pre-selected input onto the MAIN output.
6-x-2 [Fading**]: allows fading the pre-selected input to the MAIN output. You can select the duration of the
transition as indicated below:
• [1s]: 1 second transition.
• [3s]: 3 seconds transition.
• [5s]: 5 seconds transition.
• [Custom]: Select a duration from 0.5 second up to 25 seconds by 0.5 second steps.
6-x-3 [Title**]:Allows to overlay a title on the MAIN output. The title should be create using software such as
PowerPoint: the text should be bright (yellow, white) on a black background. A shadow bar is also
available for increasing the readability of the text on bright images
Select the [duration] of the transition with + ENTER between:
• [holding]: The text appears after pushing on the TAKE button, and will be removed only by a
second push on the TAKE button.
• [3s]: 3 seconds transition.
• [5s]: 5 seconds transition.
• [custom]: Select a duration from 0.5 second up to 25 seconds by 0.5 second steps.
Select the [Size] of the shadow bar with + ENTER.
Select the vertical [Position] of the shadow bar with + ENTER.
Select the [Intensity] of the shadow with + ENTER.
Select the [Effect opening] and the [effect closing] of the title between [Cut] & [Fade] with +
ENTER .
6-x-4 [PIP]: Allows displaying a picture into another picture. The PREVIEW image is reduced and displayed
onto the MAIN image.
Select the [duration] of the transition, and validate with ENTER.
• [holding]: The PREVIEW image appears after pushing on the TAKE button, and will be removed
only by a second push on the TAKE button.
• [3s]: 3 seconds transition.
• [5s]: 5 seconds transition.
• [custom]: Select a duration from 0.5 second up to 25 seconds by 0.5 second steps.
Adjust the [Image size] of the PIP with H and V, and validate with ENTER.
Set the horizontal and vertical [Image position] of the PIP with the H and V knobs, and validate with
ENTER .
Adjust the [Window size] of the PIP with the H and V knobs, and validate with ENTER. This function
allows, for example, cutting the black bars of a letterbox source.
Adjust the [Window position] of the PIP with the H and V knobs, and validate with ENTER.
Select the [Effect opening] and the [effect closing] of the PIP between [Cut] & [Fade] with
+
ENTER .
** OVX831 & QVX421.
