OCTO VUE / QUATTRO VUE
APPENDIX A / ANNEXE A
PAGE 95
COMMAND RESPONSE
COMMAND DESCRIPTION
VALUE /VALEUR
COMMANDE RÉPONSE
DESCRIPTION DE LA COMMANDE
TYPE
MIN MAX
DESCRIPTION
CONTROLS COMMANDS / COMMANDES DU MENU CONTRÔLE
YE
YE
Erase all memories.
Rd/Wr
0
1
1 = erase all memories (automatic reset).
YI
YI
Auto-lock
Rd/Wr
0
1
0 = off
1 = on.
SR
SR
Red adjustment of the FADE.
Rd/Wr
0
255
SG
SG
Blue adjustment of the FADE.
Rd/Wr
0
255
SB
SB
Green adjustment of the FADE.
Rd/Wr
0
255
SW SW
Transition.
Rd/Wr
0
5
0 = fade color
1 = clean cut
2 = frame 1
3 = frame 2
4= frame 3.
5 = frame 4
YL YL
Sync
loss
Rd/Wr
0 15
0 = black
1 = input 1
2 = input 2...................... 8 = input 8
9 = frame 1................... 10 = frame 2
12 = frame 3................. 15 = frame 6
xi
xi
Identification number byte 0 & 1.
Rd
0 65535
xj
xj
Identification number byte 2 & 3.
Rd
0 65535
xk
xk
Identification number byte 4 & 5.
Rd
0 65535
xl
xl
Identification number byte 6 & 7.
Rd
0 65535
xU VERU
Update
version.
Rd
0 65535 Example: VERU104 = version 1.4
YR
YR
DEFAULT VALUE.
Rd/Wr
0
1
1 = Default value action (automatic reset).
COMMUNICATION COMMANDS / COMMANDES DE COMMUNICATION
ne ne
Communication
port
selection
Rd/Wr
0
1
0 = RS232
1 = LAN
nr
nr
Reset of the LAN parameters.
Rd/Wr
0
1
1 = reset.
ns
ns
Store the LAN parameters.
Rd/Wr
0
1
1 = store.
na na
IP address and port selection (for
modification)
Rd/Wr
0 3
0 = all IP address / ports
1 = IP local address / local port
2 = IP remote address / remote port
3 = IP gateway address.
nw nw
First byte of the address selected by the
na command.
Rd/Wr
0 255
nx nx
Second byte of the address selected by
the na command.
Rd/Wr
0 255
ny ny
Third byte of the address selected by the
na command.
Rd/Wr
0 255
nz nz
Forth byte of the address selected by the
na command.
Rd/Wr
0 255
np np
Number of the port (local or remote)
selected by the na command.
Rd/Wr
0 65500
local port: 10000 to 10999.
remote port: 0 to 65500.
nk nk
netmask.
Rd/Wr
0
24
Value = number of bit to 0 (from right).
example: 2 255.255.255.252
3
255.255.255.248
.............
8
255.255.255.0.............
24
255.0.0.0
nt TCP
protocol
selection.
Rd/Wr
0
1
0 = UDP
1 = TCP
NOTE:
(M) = MAIN output (sortie MAIN).
Rd/Wr = Read and write command / Commande de lecture et d'écriture.
(P) = PREVIEW output (sortie PREVIEW).
Rd = Read only command / Commande de lecture uniquement.
