OCTO VUE / QUATTRO VUE
PAGE 44
Chapter 8 : TECHNICAL SPECIFICATIONS
8-1. COMPUTER & VIDEO INPUTS
• ANALOG COMPUTER
Connectors: HD15 (inputs #2 to 8) and DVI-I (input #1).
Line frequency: Up to 110 kHz.
Frame frequency:
Up to 130 Hz.
Resolution: Up to 1600 x 1200/60Hz.
Sync. types: RGBHV, RGB/S, RGsB (Sync On Green).
Levels: R, G, B = 0.7 Vp/p.
H & V Sync = TTL
Composite Sync = TTL and 0.3 V.
SOG (Sync On Green) = 0.3 V.
Impedance: R, G, B = 75 ohms.
H = 75 ohms or Hi-Z.
V = Hi-Z.
• DIGITAL COMPUTER INPUT
Connectors: DVI-I (input #1).
Format:
Digital Visual Interface (DVI)
TMDS single link.
Resolution: Up to 1600 x 1200/60Hz RB (reduced blanking) and 1920x1080/60Hz.
• RGB/S VIDEO
Connectors: HD15 (inputs #2 to 8) and DVI-I (input #1).
Frequency:
15.625 kHz / 50 Hz (625 lines).
15.734 kHz / 60 Hz (525 lines).
Levels:
R, G, B = 0.7 Vp/p.
SYNC. = 0.3 Vp/p or TTL.
Impedance: RGB = 75 ohms.
SYNC. = 75 ohms or Hi-Z.
• COMPONENT
Connectors: HD15 (inputs #2 to 8) and DVI-I (input #1).
Frequency:
15.625 kHz / 50 Hz (625 lines).
15.734 kHz / 60 Hz (525 lines).
Levels : Y = 1 Vp/p (0.7 V Luma + 0.3 V Sync.).
R-Y = 0.7 Vp/p.
B-Y = 0.7 Vp/p.
Impedance : Y,
R-Y , B-Y = 75 ohms.
• HDTV
Connectors:
HD15 (inputs #2 to 8) and DVI-I (input #1).
Formats: HD-YUV (1080i/60-50Hz, 1080p, 720p/60-50Hz, 480p/60Hz).
Levels : Y = 1 Vp/p (0.7 V + sync.).
R-Y = 1 Vp/p (0.7 V + sync.).
B-Y = 1 Vp/p (0.7 V + sync.).
Sync.:
Tri-level: ±0.3V (positive/negative).
Bi-level: 0.3V (negative).
Impedance: 75 ohms.
