Using Program Converter
7. Enter up to eight characters for the password.
• If you change your mind about assigning a password, press
J here. This will cause
the password input field to disappear and cancel password input.
8. After everything is the way you want, press
w to convert the program in accordance with
the setup.
• The message “Complete!” appears when conversion is complete. To clear the message
and return to the screen that was on the display in step 1, press
w or J.
k Converting a CFX-9850 Series Program to a fx-9860 Series Compatible
Program
To use an EA-200 control program created on the CFX-9850 Series calculator (for use on
the CFX-9850) on the E-Con2, you need to convert the program to an fx-9860 program.
Conversion can be performed using the program converter.
EA-200 Control Program for
CFX-9850 Series Convert
EA-200 Control Program for
fx-9860 Series
• To convert a program
1. Transfer the EA-200 control program created for the CFX-9850 Series to the fx-9860
main memory.
• Use the cable that comes bundled with the fx-9860 to connect its 3-pin serial port to the
3-pin serial port of the CFX-9850. For details, see Chapter 13 of this manual.
2. Perform step 1 under “To convert a setup to a program” on page
ε
-27, which displays the
program converter screen.
3. Press
1(CALC) and then press 4(→38k).
• This displays a list of programs currently in main memory.
4. Use f and c to move the highlighting of the program you want to convert, and then
press
1(EXE) or w.
• A program name input screen will appear after conversion is complete.
5. Enter up to eight characters for the program name.
• If you want to password protect the program, perform steps 6 and 7 under “To convert a
setup to a program” after inputting the program name.
6. Press
w to start conversion of the program.
• The message “Complete!” appears when conversion is complete. To clear the message,
press
w or J.
