ε
-13
Using Advanced Setup
Important!
• When the following condition exists, an “FFT Graph” setting appears in place of the
“Warm-up” setting. See “To configure the FFT Graph setting” below, for information
about configuring the “FFT Graph” setting.
- Sampling mode (page
ε
-11): Fast
6. After all the settings are the way you want, press
w.
• This returns to the Advanced Setup menu.
• To configure the Distance setting
In place of step 3 of the procedure under “To configure Sample Setup settings”, press
1 to
display a dialog box for specifying the distance the weight travels in meters.
• Specify a value in the range of 0.1 to 4 meters.
• To configure the FFT Graph setting
In place of step 5 of the procedure under “To configure Sample Setup settings”, press
1 to
display a dialog box for turning frequency characteristic graphing (FFT Graph) on and off.
To do this: Press this key:
Turn on graphing of frequency characteristics after sampling
1(On)
Turn off graphing of frequency characteristics after sampling
2(Off)
k Trigger Setup
You can use the Trigger Setup screen to specify the event that causes sampling to start (
w
key operation, etc.). The event that causes sampling to start is called the “trigger source”,
which is indicated as “Source” on the Trigger Setup screen.
The following table describes each of the six available trigger sources.
To start sampling when this happens: Select this trigger source:
When the
w key is pressed
[EXE] key
After the specified number of seconds are counted down Count Down
When input at CH1 reaches a specified value CH1
When input at the SONIC channel reaches a specified value SONIC
When the EA-200’s built-in microphone detects sound Mic
When the EA-200’s [START/STOP] key is pressed [START] key
