20100801
ε
-1
E-Con2 Overview
All of the explanations provided here assume that you are already familiar
with the operating precautions, terminology, and operational procedures of
the calculator and the EA-200.
1. E-Con2 Overview
• From the Main Menu, enter the E-Con2 mode.
E-Con2 Main Menu
• The E-Con2 mode provides the functions listed below for simple and more efficient data
sampling using the CASIO EA-200.
•
1(SET) ...............Displays a screen for setting up the EA-200.
•
2(MEMORY) ......Displays a screen for saving EA-200 setup data under a file
name.
•
3(PROGRAM) ....Performs program conversion.
• This function can be used to convert EA-200 setup data
configured using E-Con2 to an EA-200 control program (or
EA-100 control program) that can run on the fx-9860G SD/fx-
9860G.
• It also can be used to convert data to a program that can be run
on a CFX-9850 Series/fx-7400 Series calculator.
•
4(START) ..........Starts data collection.
•
5(GRAPH) .........Graphs data sampled by the EA-200, and provides tools for
analyzing graphs. Graph Analysis tools include calculation of
periodic frequency, various types of regression, Fourier series
calculation, and more.
•
6(HELP) .............Displays E-Con2 help.
• Pressing the K key (Setup Preview) or a cursor key while the E-Con2 main menu is on
the screen displays a preview dialog box that shows the contents of the setup in the current
setup memory area.
To close the preview dialog box, press
J.
Note
• For details about setup data and the current setup memory area, see “Using Setup
Memory” (page
ε
-24).
