GRAPHIC SWITCHER II™
PAGE 5
ENGLISH
GRAPHIC SWITCHER II ™ (GSW2811R)
Chapter 1 : INTRODUCTION
1-1. SUPPLIED EQUIPMENT
• 1 GRAPHIC SWITCHER II ™ (GSW2811R).
• 1 AC power supply cord.
• 1 user’s manual.
• 1 remote control software (3.5" disk).
Supplied equipment with the OPT-GSW2-VO option:
• 1 video output cable (DB9 M to 4BNC + mini DIN 4).
1-2. GENERAL INFORMATION
The seamless GRAPHIC SWITCHER II ™ inserts (PIP), cuts, fades, wipes and instantaneously mixes (no glitch)
between 16 high-resolution and TV/Video sources which can range (Auto Sync and Auto Scan) from 15 kHz up to 130
kHz (up to 1600 x 1280), with no synchronization "dropouts".
The GRAPHIC SWITCHER II ™ Up or Down scales each input to one user-programmable output format, matching
the native resolution of any projector (LCD, DLP or CRT), plasma display, video wall or multisync. monitor. All input
and output parameters and formats can be stored and saved as NON-volatile memory. In addition, several sequences
with users’ effects can be run automatically. An RS-232 Remote Control input is provided.
The GRAPHIC SWITCHER II ™ ’s outputs are:
• 1 MAIN output “PROGRAM” (BNC + HD15).
• 1 PREVIEW output “PRESET” for visualization and adjustment before the switch.
• 4 TALLY outputs (that can be selected from any of the 16 inputs to indicate who is “ON AIR”).
• TV/VIDEO output (option).
The output format can be selected in HDTV, D-ILA, SXGA, XGA
2
, SVGA, or VGA and remains constant no matter
which input is selected. This allows for a "one time" adjustment of your display device.
The GRAPHIC SWITCHER II ™ comes with a “natural color” Comb Filtering decoder with a robust sync. detection,
an enhanced 3D Auto Adaptive Motion Compensation video scaling process and a 3/2 pull down Film to video
correction (NTSC). This device takes the term “user friendly” to a new level. PIP (Picture in Picture), seamless fading
and effects combined with direct access auto-recognition inputs, makes live High End presentations better and easier
than before. It can be easily updated by software for new features.
For Multi-screen applications, 2 or 3 GRAPHIC SWITCHER II ™ ’s can be “Stacked” together and controlled by only
one Remote Control Unit (RCU2811). Also available is an optional "Show Manager" software to control 1 to 16
devices with fully automated different sequences & input selection.
1-3. GRAPHIC SWITCHER II ™ REFERENCES
REFERENCES DESIGNATIONS
GSW2811R GRAPHIC SWITCHER II ™ (without option)
GSW2811R-D1 GRAPHIC SWITCHER II ™ (with optional SDI input)
OPT-GSW2-VO Optional video outputs (Composite video + S.VIDEO + YUV)
ADD-ON-1 Optional upgrade for "Edge blending" application.
ADD-ON-2 Optional upgrade for PIP, POP & TITLE switching.
1-4. GRAPHIC SWITCHER II ™ OPTIONAL ACCESSORIES
REFERENCES DESIGNATIONS
RCU2811 REMOTE CONTROL UNIT (allows to control up to 3 GSW2811R/GSE2811R)
SWM2811 SHOW MANAGER ™ control software (allows to control up to 16 GSW2811R/GSE2811R)
KSW2811 KIT DOUBLER CONTROL FOR 3 GSW2811R/GSE2811R.
