GRAPHIC SWITCHER II™ Chapter 7 : LCD FUNCTIONS DESCRIPTION (continued)
PAGE 25
4-x-8 [PIP] = allows to display a picture into another picture. The PREVIEW image is reduced and displayed onto the
MAIN image.
c Select the [duration] of the transition , and validate with ENTER.
• [holding] = the PREVIEW image appears after pushing on the TAKE key, and will be removed
only by a second push on the TAKE key.
• [3s] = 3 seconds transition.
• [5s] = 5 seconds transition.
• [custom] = allows to select a duration from 0.5 second up to 25 seconds by 0.5 second steps.
d Select the [type] of PIP with  + ENTER.
• [normal PIP] = The PIP appears onto the MAIN output with a cut effect.
• [fade PIP] = The PIP appears onto the MAIN output with a fade effect.
e Select the [size] of the PIP (between 15 and 100%) with (or with H and V), and validate with
ENTER.
f Set the horizontal and vertical [position] of the PIP windows with the H and V knobs, and validate
with ENTER.
g Adjust the [mask size] with H and V knobs, and validate with ENTER. This function allows, for
example, cutting the black bars of a letterbox source.
h Adjust the [mask position] with the H and V knobs, and validate with ENTER.
4-x-9 [POP] = allows to change the background image when an image is inserted into another one. The transition
operates with a fading to black.
c Select the fading duration with [fade duration], and validate with ENTER.
• [1s] = 1 second transition.
• [3s] = 3 seconds transition.
• [5s] = 5 seconds transition.
• [custom] = allows to select a duration from 0.5 second up to 25 seconds by 0.5 second steps.
d Select the [size] of the POP (between 15 and 100%) with (or with H and V), and validate with
ENTER.
e Set the horizontal and vertical [position] of the POP windows with the H and V knobs, and validate
with ENTER.
f Adjust the [mask size] with H and V knobs, and validate with ENTER. This function allows, for
example, cutting the black bars of a letterbox source.
g Adjust the [mask position] with the H and V knobs, and validate with ENTER.
NOTE: The POP effect can not be use as extended effect in multi-screen application of the ADD-ON-1
upgrade.
4-5[current effect]
The LCD screen displays the current effect.
NOTE: The current effect can be directly displayed on the LCD screen by pressing the effect key.
