GRAPHIC SWITCHER II™ Chapter 7 : LCD FUNCTIONS DESCRIPTION (continued)
PAGE 21
2-5[type of screen] + ENTER.
Select an item with  + ENTER.
• [screen 4/3] = if your image is displayed on a 4/3 wall mounted projection screen shape.
• [screen 16/9] = if your image is displayed on a 16/9 wall mounted projection screen shape.
2-6[tally] + ENTER.
c First select a tally output with  + ENTER between:
d Then select an input for this tally output with  + ENTER.
2-7[tally status] + ENTER.
The LCD window displays the status of the selected tally output. Select a tally output with .
• [ON] = the tally output is active.
• [OFF] = the tally output is inactive.
2-8 [test pattern] + ENTER.
This function allows displaying a test pattern for position and size adjustments.
c Select first the output [MAIN] or [PREV] with  + ENTER.
d Then select one of the following functions with  + ENTER.
• [ON] = Displays a test pattern on the selected output.
• [OFF] = Turns OFF the test pattern.
2-9 [video output] + ENTER. (THIS MENU IS ONLY AVAILABLE WITH THE OPTIONAL VIDEO OUTPUT).
NOTE: The following functions act on the video outputs only (COMPOSITE VIDEO, S.VIDEO and COMPONENT).
2-9-1 [video standard] + ENTER.
Select the output standard for the video outputs with  + ENTER between:
• [NTSC]
• [PAL]
2-9-2 [output rate] + ENTER.
Select a function with  + ENTER between:
• [internal] = the video output is generated by the device (The output standard can be PAL or NTSC
depending on the LCD menu #2-9-1).
• [follow] = the video output is synchronized onto the referenced input (Only if LCD menu # 2-2 is not
[internal rate]. The video output standard can be PAL or NTSC depending on the standard of
the referenced input).
• [genlock] = the video output is synchronized onto an external device. For this function you must:
- Connect the supplied video cable to the DB9 connector (OPTIONAL VIDEO OUTPUT).
- Connect the reference signal device to the "genlock input" yellow cable (BNC connector).
2-9-3 [flicker adj.] + ENTER.
Select a level of anti-flicker with  + ENTER.
2-9-4 [U/Over scan] + ENTER.
Select the zoom mode with  + ENTER between:
• [underscan] = Underscan mode. The entire image is visible on the screen. Computer display mode is
underscan.
• [overscan] = Overscan mode. The image is displayed about 8 % bigger than in underscan mode, to avoid
seeing the corners and the borders. Standard TV display mode is overscan.
2-10 [soft-edge] + ENTER. (THIS MENU IS ONLY AVAILABLE WITH THE ADD-ON-1 UPGRADE).
2-11 [RGB levels] + ENTER.
This function allows to a adjust the RGB levels of the outputs. Select a color with  + ENTER and adjust the
level with  + ENTER.
