Chapter 10 : RS-232 PROGRAMMER'S GUIDE (continued) GRAPHIC SWITCHER II™
PAGE 36
10-4. COMMANDS AND RESPONSES TABLE (continued)
ASCII RESPONSE COMMAND TYPE VALUE
COMMAND DESCRIPTION MIN MAX DESCRIPTION
IMAGE COMMANDS
QO OVR Underscan / overscan (MAIN) Rd/Wr 0 1 0 = underscan 1 = overscan
qo ovr Underscan / overscan (PREVIEW) Rd/Wr 0 1 0 = underscan 1 = overscan
A ASP Input aspect ratio selection (MAIN) Rd/Wr 0 2 0 = 4/3 standard 1 = 16/9 letterbox
2 = 16/9 or WS anamorphic
a asp Input aspect ratio selection (PREV.) Rd/Wr 0 2 Identical as A command
K BLK Black level adjustment (MAIN). Rd/Wr 0 255
k blk Black level adjustment (PREVIEW). Rd/Wr 0 255
B BRG Brightness adjustment (MAIN). Rd/Wr 0 255
b brg Brightness adjustment (PREVIEW). Rd/Wr 0 255
D CON Contrast adjustment (MAIN). Rd/Wr 0 255
d con Contrast adjustment (PREVIEW). Rd/Wr 0 255
O COL Color adjustment (MAIN). Rd/Wr 0 255
o col Color adjustment (PREVIEW). Rd/Wr 0 255
T HUE Hue adjustment (MAIN). Rd/Wr 0 255
t hue Hue adjustment (PREVIEW). Rd/Wr 0 255
QP PRO Image process adjustment (MAIN). Rd/Wr 0 7 0 = level 1...................... 7 = level 8.
qp pro Image process adjustment (PREVIEW) Rd/Wr 0 7 Identical as QP command.
QF QF Optimize adjustment (MAIN). Rd/Wr 0 255
qf qf Optimize adjustment (PREVIEW). Rd/Wr 0 255
QH QH Horizontal smoothing (MAIN). Rd/Wr 0 1 0 = OFF 1 = ON
qh qh Horizontal smoothing (PREVIEW). Rd/Wr 0 1 0 = OFF 1 = ON
QV QV Vertical smoothing (MAIN). Rd/Wr 0 1 0 = OFF 1 = ON
qv qv Vertical smoothing (PREVIEW). Rd/Wr 0 1 0 = OFF 1 = ON
ym PRES PRESET (MAIN). Rd/Wr 0 1 1 = PRESET action (automatic reset).
yp pres PRESET (PREVIEW). Rd/Wr 0 1 1 = PRESET action (automatic reset).
EFFECTS COMMANDS
E EFF Effect selection. Rd/Wr 0 20 Please see value description (next section).
ed EFD Effect duration selection. Rd/Wr 5 255 Please see value description (next section).
eh EFH Horizontal position of the effect. Rd/Wr 0 255
ev EFV Vertical position of the effect (PIP...) Rd/Wr 0 255
es EFS Vertical size of the effect (PIP,
SHADOW...) Rd/Wr 0 200 0 = 0 % 200 = 100 %
(For PIP : MIN value = 30).
eH EFs Horizontal size of the PIP. Rd/Wr 0 255 0 = 0 % 200 = 100 %
ex EFx Horizontal shape position (PIP) or
Intensity (Shadow title). Rd/Wr 0 255
ey EFy Vertical shape position (PIP). Rd/Wr 0 255
eX EFX Horizontal shape size (PIP). Rd/Wr 0 200
eY EFY Vertical shape size (PIP). Rd/Wr 0 200
g EON Effect in progress. Rd 0 1 0 = no effect in progress. 1 = effect in progress.
xC ICHS New background source during a POP. Rd 0 21 Identical as c command.
TALLY OUTPUTS COMMANDS
ja TALA Input number for TALLY1 Rd/Wr 1 21 Please see value description (next section).
jb TALB Input number for TALLY2. Rd/Wr 1 21 Please see value description (next section).
jc TALC Input number for TALLY3. Rd/Wr 1 21 Please see value description (next section).
jd TALD Input number for TALLY4. Rd/Wr 1 21 Please see value description (next section).
JA TAON TALLY1 status. Rd 0 1 0 = TALLY1 inactive 1 = TALLY1 active.
JB TBON TALLY2 status. Rd 0 1 0 = TALLY2 inactive 1 = TALLY2 active.
JC TCON TALLY3 status. Rd 0 1 0 = TALLY3 inactive 1 = TALLY3 active.
JD TDON TALLY4 status. Rd 0 1 0 = TALLY4 inactive 1 = TALLY4 active.
