Chapter 7 : LCD FUNCTIONS DESCRIPTION (continued) GRAPHIC SWITCHER II™
PAGE 26
4-6[sequence mode] + ENTER.
This mode allows programming a sequence of transition. The sequence can also be activated at any time during the
show, and controlled step by step (one step = pre-selection + transition) by one key only: the STEP key. This function
allows to simplify the use of the device during a show.
4-6-1 [list sequence] + ENTER.
This function allows to verify the programmed sequence. Turn the  knob to display the list.
4-6-2 [play sequence] + ENTER.
This function allows to start or stop the programmed sequence.
IMPORTANT: Before starting, verify that the correct input is displayed onto the MAIN output.
c Select start with  and press ENTER to start the programmed sequence. The STEP key is blinking and
the first pre-selected source is displayed onto the PREVIEW output. Press the STEP key to execute the first
transition and pre-select the next source and so on.
NOTE: For holding effect (i.e. : holding PIP): the first push on STEP allows to activate the effect and a
second push on STEP stops the effect.
d To stop the sequence press ENTER, the LCD menu displays [play sequence]: select stop with  and
validate with ENTER. The STEP key turns OFF.
4-6-3 [add step] + ENTER.
This function allows to add a step into your sequence. A step is composed of an input pre-selection and a
transition. Each new step is added at the end of your sequence.
Proceed as follow:
c Select start and validate with ENTER. The STEP key turns ON.
d Pre-select an input with the input selection keys (the key is blinking and the image appears onto the
PREVIEW output).
e Select a transition: Press one of the four effect keys (1, 2, 3, 4) and select the needed effect.
f Press on STEP to add this new STEP into your sequence. The transition is displayed onto the MAIN output.
NOTE: For holding effect (i.e. : holding PIP): the first push on STEP allows to activate the effect and a
second push on STEP to stops the effect.
g Repeat the operations d, e, f to add any new steps.
NOTE: You can add up to 40 STEPS into your sequence.
h Select stop to deactivate the add step function. The STEP key turns OFF.
4-6-4 [erase last] + ENTER.
Erases the last step of the sequence.
4-6-5 [clear sequence] + ENTER.
Erases all of the sequence.
