GRAPHIC SWITCHER II™
PAGE 19
Chapter 7 : LCD FUNCTIONS DESCRIPTION
1 [INPUT MENU] + ENTER.
1-1 [Input Status] + ENTER.
Select
[MAIN = x] or [PREV = x] with  + ENTER.
• [MAIN = x] = Number of the selected input.
• [SYNC = xxxx] = Sync. type: [H+V+] = Separate H & V Sync. with polarities.
[COMP] = Composite Sync.
[SOG] = Sync. On Green.
• [XGA 48KHz/60Hz] = Name of the format, line / frame frequency [kHz/Hz], [i] = interlaced format.
• [NO INPUT] = No signal detected on this input.
• [OUT OF RANGE] = The input signal is not compatible with the input range of the device.
1-2 [RGB/YUV inputs] + ENTER.
c Select first the RGB/YUV inputs with  + ENTER.
d Then select the signal connected to the input with  + ENTER between:
• [SDTV YUV] = Component (YUV) video signal.
• [SDTV RGBS TTL] = RGB/S video signal with TTL Composite Sync.
• [SDTV RGB SOG] = RGsB video signal with analog Composite Sync. On Green.
• [SDTV RGBS ana.] = RGB/S with an analog Composite Sync. (0.3 Vp/p).
• [Computer SOG] =
RGsB Computer signal (Sync. on Green).
• [Computer HV/C.] = RGBHV or RGBS Computer signals.
• [HDTV] =
720p & 1080i with bi-level sync only (RGBHV).
NOTE : SDTV means Standard Definition TV (15 kHz).
1-3 [Video standard] + ENTER.
Select an item with  + ENTER.
• [auto] = Automatic recognition of the video standard for all inputs. NTSC / PAL / SECAM / Black & White
are detected automatically; if not, please use the
[manual] setting.
• [manual] = Manual selection of the video standard for each input.
c Select first an input with  + ENTER.
d Then select the video standard with  + ENTER.
• [auto] = Automatic detection.
• [NTSC] = NTSC detection only.
• [PAL] = PAL detection only.
• [SECAM] = SECAM detection only.
• [Black & White] = Black and White detection only.
1-4 [Used inputs] + ENTER.
This function allows to disable the unused input keys.
Select an input
[#1, to SDI] with  and press ENTER to change the selection.
• [#1 used] = Input #1 used (KEY 1 is low lighted).
• [#6 unused] = Input #6 unused (KEY 6 is OFF).
1-5 [H sync load] + ENTER.
Select
[#1, #2, #3...] with  and press ENTER to change the selection.
• [#1 75Ω load] = The H Sync. of the input #1 is set under 75 ohms.
• [#2 Hi-Z] = The H sync. of the input #2 is set under high impedance.
1-6 [CV/SV mode] + ENTER.
Select the COMPOSITE & S.VIDEO mode corresponding to your configuration.
• [8 CV ] = 8 COMPOSITE inputs (# 9 to 16) are enabled.
• [6 CV + 1 SV] = 6 COMPOSITE inputs (# 9 to 14) and 1 S.VIDEO inputs (# S1) are enabled.
• [4 CV + 2 SV] = 4 COMPOSITE inputs (# 9 to 12) and 2 S.VIDEO inputs (# S1 & S2) are enabled.
• [2 CV + 3 SV] = 2 COMPOSITE inputs (# 9 & 10) and 3 S.VIDEO inputs (# S1 to S3) are enabled.
• [ 4 SV] = 4 S.VIDEO inputs (# S1 to S4) are enabled.
