Chapter 7 : LCD FUNCTIONS DESCRIPTION (continued) GRAPHIC SWITCHER II™
PAGE 22
3 [IMAGE MENU] + ENTER.
NOTE: The IMAGE adjustments act on the selected and/or the pre-selected input. Select [MAIN] to adjust the image
displayed on the MAIN output and select [PREV] to adjust the image displayed on the PREVIEW output.
• If the selected input is a COMPUTER signal (LCD menu # 1-2 = Computer---) the IMAGE MENU displays the
following items :
3-1 [Black level] + ENTER.
Adjust the black level with  + ENTER.
3-2 [H. smooth] + ENTER.
• [ON] = Vertical smoothing active.
• [OFF] = Vertical smoothing inactive.
3-3 [V. smooth] + ENTER.
• [ON] = Horizontal smoothing active.
• [OFF] = Horizontal smoothing inactive.
3-4 [optimize] + ENTER.
[#3 optimize] = Optimization of the input #3 image.
3-5 [aspect ratio] + ENTER.
Select the Aspect Ratio of your input source with  + ENTER.
• [4/3 standard] = 4/3 input format.
• [letterbox] =
Letterbox input format.
• [16/9] = 16/9 input format.
3-6 [pos status] + ENTER.
Display the horizontal and vertical position status.
3-7 [size status] + ENTER.
Display the horizontal and vertical size status.
3-8 [preset] + ENTER.
This function allows setting all the image parameters to the factory settings. Select [YES] and validate with ENTER.
• If the selected input is a VIDEO signal (COMPOSITE, S.VIDEO, COMPONENT, RGsB or RGBS) the IMAGE
MENU display the following items :
3-1 [U / Overscan] + ENTER.
Select an item with  + ENTER.
• [underscan] = Underscan mode. The entire image is visible on the screen. Computer display mode is underscan.
• [overscan] = Overscan mode. The image is displayed about 8 % bigger than in underscan mode, to avoid seeing
the corners and the borders. Standard TV display mode is overscan.
3-2 [aspect ratio] + ENTER.
Select the Aspect Ratio of your input source with  + ENTER.
• [4/3 standard] = 4/3 input format.
• [letterbox] = Letterbox input format.
• [WS anamorphic] = Wide Screen anamorphic input format.
3-3 [brightness] + ENTER.
Adjust the brightness with  + ENTER.
3-4 [contrast] + ENTER.
Adjust the contrast with  + ENTER.
