Standard window installation continued – Friedrich Kuhl Series 28000 BTU Window Air Conditioner Installation and Operation Manual Manuel d'utilisation
Page 34
Advertising
34
35
Figure 63
FRR019
Figure 64
FRR020
Standard Window Installation continued
ALTERNATE METHOD B
#10-24 FLAT WELD NUT
3
/
8
″ SLOPE DOWN
OUTSIDE WALL
#10-24 SCREW
CUT TO FIT DIMENSION “A”
AND BEND DOWN TO FORM
A VERTICAL LEG.
DIMENSION “A”
STONE LEDGE
CUT HERE
DISCARD
SHADED AREA
A
SUBTRACT
1
/
8
″ FROM DIMENSION “B” AND
MEASURE FROM THE EDGE OF WINGBOARD
(ITEM 8), MARK, SCORE AND CUT WITH
APPROPRIATE CUTTING TOOL.
MEASURE DISTANCE “B” TO INSIDE
OF THE CHANNEL ON EACH SIDE.
CUT HERE AND DISCARD
CENTER WASTE MATERIAL
WINGBOARD
B
B
B
B
