32
33
Figure 61
FRR017
Figure 62
FRR018
FOR LEDGES
ALTERNATE METHOD A
Standard Window Installation continued
#10-24 SCREW
3
/
8
″ SLOPE DOWN
#12 x 2″ SHEET METAL
SCREW (ITEM 4)
CONDENSER
AIR INLETS
#10-24 FLAT WELD NUT
SPACER
ADJUST IN OR OUT TO REST
ON THE LEDGE
STONE LEDGE
#10-24 FLAT WELD NUT
SECURE THE LONGEST SIDE OF
THE BRACKET TO THE SHELL
3
/
8
″ SLOPE DOWN
#10-24 SCREW
STRAIGHTEN TAB TO LAY FLAT
ALONG THE BOTTOM RAIL OF
THE SHELL
STONE LEDGE
