Control Panel Operation
The TM Menu continued
Auto mode selected. See Figure 23.
Set the cool setpoint for your first timer period using the arrow buttons.
The cooling mode timer only sets the cool setpoint. See Figure 24.
Next, set the heat setpoint for your first timer period. The heating mode
timer only sets the heat setpoint. See Figure 25.
Figure 23
MENU
Figure 24
MENU
Figure 25
Figure 26
Note: The auto mode timer sets both the cool and heat setpoint.
Set the time to start the first timer period. See Figure 26.
