TNC 320 HEIDENHAIN
359
1
0
.8 F
o
nctions spéciales
3
-
Axe réfléchi actif
0: image miroir inactive
+1: axe X réfléchi
+2: axe Y réfléchi
+4: axe Z réfléchi
+64: axe U réfléchi
+128: axe V réfléchi
+256: axe W réfléchi
Combinaisons = somme des différents axes
4
1
Facteur échelle actif axe X
4
2
Facteur échelle actif axe Y
4
3
Facteur échelle actif axe Z
4
7
Facteur échelle actif axe U
4
8
Facteur échelle actif axe V
4
9
Facteur échelle actif axe W
5
1
ROT. 3D axe A
5
2
ROT. 3D axe B
5
3
ROT. 3D axe C
6
-
Inclinaison plan d'usinage act./inact. (-1/0) en mode
Exécution de programme
7
-
Inclinaison plan d'usinage act./inact. (-1/0) en mode manuel
Décalage actif du point zéro, 220
2
1
Axe X
2
Axe Y
3
Axe Z
4
Axe A
5
Axe B
6
Axe C
7
Axe U
8
Axe V
9
Axe W
Nom du groupe, n° ident.
Numéro
Indice
Signification
