VIO1600 & ULTRA VIO
PAGE 7
VIO1600 TM & ULTRA VIO TM
Chapter 1 : INTRODUCTION
1-1. ACCESSORIES SUPPLIED WITH YOUR DEVICE
• 1 AC Power supply cord.
• 1 VGA cable (HD15 male / male connector).
• 1 S.VIDEO (Y/C) cable (4-pin mini DIN male / male connectors).
• 1 BNC (x5) to BNC (x5) cable (male / male).
• 1 DVI-D / DVI-D cable (male / male).
• 1 DVI / HD15 adaptor (male / female).
• 1 CD-ROM (Remote Control Software).
• 1 User’s Manual.
Supplied equipment with the OPT-RMK1 option:
• 2 rack mount brackets.
• 6 screws.
1-2. GENERAL INFORMATION
VIO1600 by Analog Way is a multipurpose Switcher / Converter / Interface, with 3 universal inputs. It accepts a
large range of formats, from computer to video and HDTV, in analog or digital format, and a large range of connectors:
BNC, HD15, DVI, mini DIN 4, Cinch, RCA. The output provides the same diversity of formats, type of signals and
connectors.
- 3 UNIVERSAL INPUTS: Each input features an active loopthrough (monitoring) for easy control of the sources and
accepts the following TV formats:
NTSC/PAL/SECAM, S.VIDEO, RGB or YUV, HDTV in HDYUV and computer formats: up to UXGA.
Input 1 also accepts DVI-I. An optional 10 bit SDI / HDSDI input is available on input 2.
- OUTPUT: VIO1600 generates various output formats: PAL, NTSC, Y/C, YUV or computer, in analog RGB or
digital DVI.
More than a powerful multi-format converter, VIO1600 is also a smooth and fast Switcher.
VIO1600 is a universal device with four functions in one: Scan Converter, Scaler, Standard Converter with TBC and
Interface.
VIO1600 offers high quality image thanks to its automatic 3:2 and 2:2 pull down circuitry, auto adaptative motion
compensation, auto centering, time base corrector, frame rate converter and follower and multilevel anti-flicker. The
configurable adjustments recorded in a non volatile memory.
The ULTRA VIO includes all the features of the VIO1600 and in addition is equipped with an 10 bits SDI/HDSDI
input (input 2), an analog genlock input and a SDI/HDSDI output.
VIO1600 & ULTRA VIO are highly flexible devices, essential in complex installations. There are useful to solve all
last minute issues. VIO1600 & ULTRA VIO are your all in one Versatile Input/Output tools.
1-3. DEVICES & OPTIONS REFERENCES
REFERENCE DESIGNATION
V301 VIO1600.
V301-ID1
VIO1600 (same V301 with SDI/HDSDI input).
VU301-IOD1 ULTRA VIO (same V301 with SDI/HDSDI input, analog genlock input and SDI/HDSDI output).
OPT-LAN LAN communication port (optional).
OPT-RMK1 Rack Mount Kit (optional).
