Chapter 7 : TECHNICAL SPECIFICATIONS (continued)
VIO1600 & ULTRA VIO
PAGE 30
7-1. COMPUTER & VIDEO INPUTS (continued)
• S.VIDEO
Connectors:
4-pin mini DIN (input #3), RCA (input #3), BNC (input #1), HD15 (inputs #2 & 3) and DVI-I
(input #1).
Standards:
PAL (15.625 kHz / 50 Hz - 625 lines) or NTSC (15.734 kHz / 60 Hz - 525 lines).
Levels:
Y = 1 Vp/p.
C = 0.3 Vp/p.
Impedance:
75 ohms.
• COMPOSITE VIDEO
Connectors:
BNC (inputs #1 & 2), RCA (input #3), HD15 (inputs #2 & 3) and DVI-I (input #1).
Standards:
PAL / SECAM (15.625 kHz / 50 Hz - 625 lines) or NTSC (15.734 kHz / 60 Hz - 525 lines).
Level: 1
Vp/p.
Impedance: 75
ohms.
• SDI (V301-ID1 & VU301-IOD1 models only):
Connector:
BNC (input #2).
Signal:
270 Mbps serial digital input conforming to SMPTE 259M.
Impedance: 75
ohms.
• HDSDI (V301-ID1 & VU301-IOD1 models only):
Connector:
BNC (input #2).
Data rate:
720p @ 59.94 or 60 Hz:
1.5 Gbps serial digital input conforming to SMPTE 296M.
1080i @ 59.94 or 50 or 60 Hz: 1.5 Gbps serial digital input conforming to SMPTE 274M.
Impedance: 75
ohms.
7-2. GENLOCK INPUT (VU301-IOD1 model only)
Connector:
BNC.
Standards: SDTV
black
burst
or black HD-YUV.
Levels: 1
Vp/p.
Impedance:
75 ohms or Hi-Z.
