VIO1600 & ULTRA VIO
APPENDIX A / ANNEXE A
PAGE 65
COMMAND RESPONSE
COMMAND DESCRIPTION
VALUE /VALEUR
COMMANDE RÉPONSE DESCRIPTION DE LA COMMANDE
TYPE
MIN MAX
DESCRIPTION
STATUS COMMANDS / COMMANDES D'ÉTATS
U
UNIT
Measures unity in kHz.
Rd
0 65535
IL ILD
This command allows to calculate the
input line frequency in Hz.
Rd
0 65535 Line frequency (in kHz) = (UNIT VALUE) ÷
(ILD VALUE).
ID IFD
This command allows to calculate the
input frame frequency in Hz.
Rd
0 65535
Frame frequency (in Hz) = (Line frequency in
Hz)
÷ (IFD VALUE).
IP
IPS
Input Sync. detection.
Rd
0
1
0 = not detected
1 = Sync. detected.
IH
IHP
Sign of the horizontal input Sync.
Rd
0
1
0 = negative
1 = positive.
IV
IVP
Sign of the vertical input Sync.
Rd
0
1
0 = negative
1 = positive.
IK
IST
Input Sync type detection.
Rd
0 3
0 = H &V.
2 = SOG.
1 = Composite (TTL). 3 = Composite (ana)
II
IIN
Interlaced signal detection.
Rd
0
1
0 = not interlaced
1 = interlaced.
IO
IOO
"Out of range" signal detection.
Rd
0
1
0 = In range
1 = Out of range.
IF
IFA
Standard input signal detection.
Rd
0 34
XF
REFF
Standard of the synchronized input.
Rd
0 34
0 = no signal.
1 = not compatible.
2 = NTSC (3.58/60).
3 = PAL (4.43/50).
4 = SECAM (50Hz).
5 = B & W (50Hz).
6 = B & W (60Hz).
7 = YUV 50 Hz.
8 = YUV @ 60 Hz.
9 = RGB @ 50 Hz.
10 = RGB @ 60 Hz.
11 = VGA1 350L.
12 = VGA2 400L.
13 = VGA3 480L.
14 = PLASMA 42".
15 = WVGA
16 = SVGA.
17 = 720pc
18 = MAC.
19 = XGA.
20 = WXGA.
21 = SWXGA.
22 = PLASMA 50".
23 = MAC 21".
24 = SXGA.
25 = UXGA.
26 = SXGA+
27 = 1035i @ 50 Hz.
28 = 1035i @ 60 Hz.
29 = 1080i @ 50 Hz.
30 = 1080i @ 60 Hz.
31 = 480p @ 60 Hz.
32 = 720p @ 50 Hz.
33 = 720p @ 60 Hz.
34 = 1080sf24
XT REFT
Frame frequency of the synchronized
input.
Rd
0 65535 Value in hundredth of Hz.
XA REFA
Synchronized
input.
Rd
0 1
0 = Internal rate
1 = follow input #1.
ut TKEV
Transition
availability.
Rd
0 1
1 = New input ready to commute.
NOTE: Rd = Read only command / Commande de lecture.
Rd/Wr = Read and write command / Commande de lecture et d'écriture.
