Chapter 7 : TECHNICAL SPECIFICATIONS
7-1. COMPUTER & VIDEO INPUTS
• ANALOG COMPUTER
Connectors:
HD15 (inputs #2 & 3), BNC (input #1) and DVI-I (input #1).
Line frequency:
Up to 110 kHz.
Frame frequency:
Up to 130 Hz.
Resolution:
Up to 1600 x 1200 @ 60Hz.
Sync. types:
RGBHV, RGB/S, RGsB (Sync On Green).
Levels:
R, G, B = 0.7 Vp/p.
H & V Sync = TTL
Composite Sync = TTL and 0.3 V.
SOG (Sync On Green) = 0.3 V.
Impedance:
R, G, B = 75 ohms.
H = 75 ohms or Hi-Z.
V = Hi-Z.
• DIGITAL COMPUTER INPUT
Connectors:
DVI-I (input #1).
Format:
Digital Visual Interface (DVI)
TMDS single link.
Resolution:
Up to 1600 x 1200 @ 60Hz BR (reduced blanking).
• RGB/S VIDEO
Connectors:
HD15 (inputs #2 & 3), BNC (input #1) and DVI-I (input #1).
Frequency:
15.625 kHz / 50 Hz (625 lines).
15.734 kHz / 60 Hz (525 lines).
Levels:
R, G, B = 0.7 Vp/p.
SYNC. = 0.3 Vp/p or TTL.
Impedance:
RGB = 75 ohms.
SYNC. = 75 ohms or Hi-Z.
• COMPONENT
Connectors:
RCA (input #3), BNC (input #1), HD15 (inputs #2 & 3) and DVI-I (input #1).
Frequency:
15.625 kHz / 50 Hz (625 lines).
15.734 kHz / 60 Hz (525 lines).
Levels:
Y = 1 Vp/p (0.7 V Luma + 0.3 V Sync.).
R-Y = 0.7 Vp/p.
B-Y = 0.7 Vp/p.
Impedance: Y,
R-Y
,
B-Y = 75 ohms.
• HDTV
Connectors:
RCA (input #3), BNC (input #1), HD15 (inputs #2 & 3) and DVI-I (input #1).
Formats:
720p &1080i.
Levels:
Y = 1 Vp/p (0.7 V + sync.).
R-Y = 1 Vp/p (0.7 V + sync.).
B-Y = 1 Vp/p (0.7 V + sync.).
Sync.:
Tri-level: ±0.3V (positive/negative).
Bi-level:
0.3V
(negative).
Impedance: 75
ohms.
