APPENDIX A / ANNEXE A VIO1600 & ULTRA VIO
PAGE 62
A-4: COMMANDS AND RESPONSES TABLE A-4: TABLE DES COMMANDES ET RÉPONSES
COMMAND RESPONSE
COMMAND DESCRIPTION VALUE /VALEUR
COMMANDE RÉPONSE DESCRIPTION DE LA COMMANDE
TYPE
MIN MAX DESCRIPTION
FRONT PANEL COMMANDS / COMMANDES DE LA FACE AVANT
CC CH Selected input. Rd 0 3
CN CHN Input selection. Rd/Wr 0 3
1 = INPUT #1
2 = INPUT #2
3 = INPUT #3
yC ACAD Image centering. Rd/Wr 0 1 1 = CENTERING action (automatic reset).
z FRZ FREEZE. Rd/Wr 0 1 0 = inactive 1 = active.
FO OBLK BLACK output screen selection. Rd/Wr 0 1 1 = BLACK.
INPUT COMMANDS / COMMANDES D'ENTRÉE
PC PCH Input selection for adjustment. Rd/Wr 0 3
0 = All inputs 1 = INPUT #1
2 = INPUT #2 3 = INPUT #3
PE PEN Input disabling (according to PCH). Rd/Wr 0 1 0 = Input disable 1 = Input enable
PL PLD H sync load selection (according PCH) Rd/Wr 0 1 0 = Hi-Z load 1 = 75Ω load
PR PRGB
Input signal type selection. (according
to PCH).
Rd/Wr 0 12
0 = Computer H&V/C 1 = Computer SOG
2 = Computer DVI
3 = SDTV Composite
4 = SDTV S.VIDEO 5 = SDTV YUV
6 = SDTV RGBS
7 = SDTV RGsB
8 = SDTV RGBS ana. 9 = SDI
10 = HDTV YUV
11 = HDSDI
12 = Audio only
PI PSTD
Input standard selection (according to
PCH).
Rd/Wr 0 4
0 = NTSC / PAL / SECAM
1 = NTSC
2 = PAL
3 = SECAM 4 = Black & White
PP PPRC VCR mode (according to PCH). Rd/Wr 0 1 0 = OFF 1 = ON
OUTPUT COMMANDS / COMMANDES DE SORTIE
FM OFMT Output format selection. Rd/Wr 0 44
0 = SDTV NTSC 1 = SDTV PAL
2 = VGA@50 3 = VGA@60
4 = VGA@72 5 = VGA@75
6 = WVGA@50 7 = WVGA@60
8 = WVGA@72 9 = WVGA@75
10 = SVGA@50 11 = SVGA@60
12 = SVGA@72 13 = SVGA@75
14 = 1280x720@50 15 = 1280x720@60
16 = 1280x720@72 17 = 1280x720@75
18 = XGA@50
19 = XGA@60
20 = XGA@72 21 = XGA@75
22 = WXGA@50 23 = WXGA@60
24 = WXGA@72 25 = WXGA@75
26 = SWXGA@50 27 = SWXGA@60
28 = SWXGA@72 29 = SWXGA@75
30 = SXGA@50 31 = SXGA@60
32 = SXGA@72 33 = SXGA@75
34 = SXGA+@50 35 = SXGA+@60
36 = SXGA+@72 37 = SXGA+@75
38 = UXGA@50 39 = UXGA@60
40 = 480p@60 41 = 720p@50
42 = [email protected] 43 = 720p@60
44 = 1080i@50
FG OSIG Video output type selection. Rd/Wr 0 4
0 = Composite video 1 = S.VIDEO
2 = YUV
3 = RGBS 4 = RGsB
FD ODVI DVI output selection. Rd/Wr 0 1 0 = DVI disable 1 = DVI enable.
FS OSDI SDI output selection Rd/Wr 0 1 0 = SDI out disable 1 = SDI out enable.
XR REFR Output rate selection. Rd/Wr 0 1 0 = Internal rate 1 = follow input #1.
FY OSYN Output sync selection. Rd/Wr 0 2 0 = H &V 1 = Composite 2 = SOG.
FV OOVR Underscan / overscan (video output). Rd/Wr 0 1 0 = underscan 1 = overscan
pm PAT Test pattern. Rd/Wr 0 5
0 = no pattern 1 = centering
2 = color bar 3 = grey scale
4 = grid 5 = burst
NOTE: Rd = Read only command / Commande de lecture. Rd/Wr = Read and write command / Commande de lecture et d'écriture.
