Chapter 7 : TECHNICAL SPECIFICATIONS (continued) VIO1600 & ULTRA VIO
PAGE 32
7-3. OUTPUTS (continued)
• COMPOSITE VIDEO
Connectors: HD15, DVI-I and BNC.
Standards: PAL / SECAM (15.625 kHz / 50 Hz - 625 lines) or NTSC (15.734 kHz / 60 Hz - 525 lines).
Level: 1 Vp/p.
Impedance: 75 ohms.
• SDI (VU301-IOD1 model only):
Connector: BNC.
Formats: 480i (NTSC) or 576i (PAL).
Data rate: 270 Mbps serial digital conforming to SMPTE 259M.
Impedance: 75 ohms.
• HDSDI (VU301-IOD1 model only):
Connector:
BNC.
Formats: 720p (@ 50, 59.94 or 60 Hz) or 1080i (@ 50, 59.94 or 60 Hz.)
Data rate: 1.5 Gbps serial digital conforming to SMPTE 296M / SMPTE 274M.
Impedance: 75 ohms.
7-4. AUDIO INPUTS
Connectors: RCA (inputs #1 & 3) and Jack 3.5 (input #2).
Levels: Vi = + 18 dBu (max).
Zi = 20 kΩ unbalanced.
7-5. AUDIO OUTPUT
Connectors: RCA (inputs #1 & 3) and Jack 3.5 (input #2).
Levels: Vo = + 18 dBu (+12 dBu with 300Ω load).
Zo = 300 Ω unbalanced.
G = 0 dB nominal, G = + 6 dB / - ∞ adjustable with Master volume.
7-6. COMMUNICATION PORTS
• RS-232 (on DB9 female connector)
Data Rate: 9600 Bauds, 8 data bits, 1 stop bit, no parity bit, no flow control.
• LAN (Optional on RJ45 connector)
Protocol: TCP (Transmission Control Protocol) / UDP (User Datagram Protocol).
Data Rate: 10 / 100 Mbps.
LED functions (on RJ45 connector): Top LED Bottom LED Meaning
OFF OFF No link
OFF ON 100 BASE-T link.
ON OFF 10 BASE-T link.
7-7. ENVIRONMENTAL
Power Supply: Internal CE / UL / CSA / IEC 950 (50 W), universal, automatic.
Input: 100 VAC to 250 VAC; 50-60 Hz; I = 1 A Max.
Storage Temperature: - 25 °C to + 85 °C (- 13 °F to + 185 °F).
Operating temperature: 0 °C to + 50 °C (32 °F to 122 °F).
Maximum ambient operating temperature: < 40 °C (< 104 °F).
Hygrometry: 10% to 80% (without condensation).
Dimensions: D 300 x W 452 x H 44 mm / D 11.8" x W 17.8" x H 1.74".
Compatible with the 19" rack (height = 1 unit).
Weight: 3.8 kg / 8.4 lbs.
