VIO1600 & ULTRA VIO
Chapter 7 : TECHNICAL SPECIFICATIONS (continued)
PAGE 31
7-3. OUTPUTS
• ANALOG COMPUTER
Connectors:
HD15, DVI-I and BNC.
Line frequency:
Up to 110 kHz.
Frame frequency:
Up to 130 Hz.
Resolution:
Up to 1600 x 1200.
Sync. types:
RGBHV, RGB/S, RGsB (Sync On Green).
Levels:
R, G, B = 0.7 Vp/p.
H & V Sync = TTL
Composite Sync = TTL and 0.3 V.
SOG (Sync On Green) = 0.3 V.
Impedance:
R, G, B = 75 ohms.
• DIGITAL COMPUTER
Connector:
DVI-I.
Format:
Digital Visual Interface (DVI)
TMDS
Single
link.
Resolution:
Up to 1600 x 1200 @ 60 Hz BR (reduced blanking)
• RGB/S VIDEO
Connectors:
HD15, DVI-I and BNC.
Frequency:
15.625 kHz - 50 Hz (625 lines) or 15.734 kHz - 60 Hz (525 lines).
Levels:
R, G, B = 0.7 Vp/p.
SYNC. = 0.3 Vp/p or TTL.
Impedance:
RGB = 75 ohms.
SYNC. = 75 ohms or Hi-Z.
• COMPONENT
Connectors:
HD15, DVI-I and BNC.
Frequency:
15.625 kHz - 50 Hz (625 lines) or 15.734 kHz - 60 Hz (525 lines).
Levels:
Y = 1 Vp/p, R-Y = 0.7 Vp/p, B-Y = 0.7 Vp/p.
Impedance: Y,
R-Y
,
B-Y = 75 ohms.
• HDTV
Connectors:
HD15, DVI-I and BNC.
Formats:
480p & 720p.
Levels:
Y = 1 Vp/p, R-Y = 0.7 Vp/p, B-Y = 0.7 Vp/p.
Sync.:
Tri-level: ±0.3V (positive/negative).
Bi-level:
0.3V
(negative).
Impedance: 75
ohms.
• S.VIDEO
Connectors:
4-pin mini DIN, HD15, DVI-I and BNC.
Standards:
PAL (15.625 kHz / 50 Hz - 625 lines) or NTSC (15.734 kHz / 60 Hz - 525 lines).
Levels:
Y = 1 Vp/p.
C = 0.3 Vp/p (Chroma Burst).
Impedance:
75 ohms.
