VIO1600 & ULTRA VIO
APPENDIX A / ANNEXE A
PAGE 63
COMMAND RESPONSE
COMMAND DESCRIPTION
VALUE /VALEUR
COMMANDE RÉPONSE DESCRIPTION DE LA COMMANDE
TYPE
MIN MAX
DESCRIPTION
IMAGE COMMANDS / COMMANDES DU MENU IMAGE
H HP
Horizontal
position.
Rd/Wr
0
255
V VP
Vertical
position.
Rd/Wr
0
255
W HW
Horizontal
size.
Rd/Wr
0
255
S VS
Vertical
size.
Rd/Wr
0
255
ZH
ZHP
Zoom horizontal position.
Rd/Wr
0
255
ZV
ZVP
Zoom vertical position.
Rd/Wr
0
255
ZW ZHS
Zoom
horizontal size.
Rd/Wr
0
255
ZS
ZVS
Zoom vertical size.
Rd/Wr
0
255
QA
ASP
Input aspect ratio selection.
Rd/Wr
0
2
0 = 4/3 standard
1 = 16/9 letterbox
2 = WS anamorphic.
QS
OASP
Output aspect ratio selection
Rd/Wr
0
3
0 = Standard
1 = Full screen
2 = Crop
3 = Custom (adjustment with ZH, ZV, ZW, ZS)
B BRG
Brightness adjustment (video)or
Black
level adjustment (computer).
Rd/Wr
0 255
D CON
Contrast
adjustment
(video). Rd/Wr
0
255
O
COL
Color adjustment (video).
Rd/Wr
0
255
T
HUE
Hue adjustment (video NTSC).
Rd/Wr
0
255
QO
OVR
Underscan / overscan (video).
Rd/Wr
0
1
0 = underscan
1 = overscan
QP
PRO
Sharpness adjustment (video).
Rd/Wr
0
7
0 = standard level
1 = level 1
2 = level 2.................. 7 = level 7.
QR
RLV
Red level adjustment (computer).
Rd/Wr
0
127
QG GLV
Green
level
adjustment (computer).
Rd/Wr
0
127
QB
BLV
Bleu level adjustment (computer).
Rd/Wr
0
127
MC CLK
Pixels
clock
adjustment (computer).
Rd/Wr
0 65535
QF
FLK
Anti-flicker level (video output)
Rd/Wr
0
3
MP
PHA
Pixels phase adjustment (computer).
Rd/Wr
0
31
yP PRES
PRESET.
Rd/Wr
0
1
1 = PRESET action (automatic reset).
AUDIO COMMANDS / COMMANDES DU MENU AUDIO
RV
AVOL
Master volume adjustment.
Rd/Wr
0
255
RO
AMOD
Auto follow or breakaway mode.
Rd/Wr
0
1
0 = auto follow
1 = breakaway
RC
ACH
Audio input selection.
Rd/Wr
1
3
1 = AUDIO IN #1.
2 = AUDIO IN #2
3 = AUDIO IN #3
RL
ALVL
Audio level (works with PC command). Rd/Wr
0
63
RB
ABAL
Audio balance (works with PC).
Rd/Wr
0
63
RM AMUT
Audio
mute.
Rd/Wr
0
1
0 = MUTE OFF
1 = MUTE ON
RS
AMNO
Mono/stereo mode selection.
Rd/Wr
0
1
0 = STEREO
1 = MONO
NOTE: Rd = Read only command / Commande de lecture.
Rd/Wr = Read and write command / Commande de lecture et d'écriture.
