APPENDIX A / ANNEXE A
VIO1600 & ULTRA VIO
PAGE 64
COMMAND RESPONSE
COMMAND DESCRIPTION
VALUE /VALEUR
COMMANDE RÉPONSE DESCRIPTION DE LA COMMANDE
TYPE
MIN MAX
DESCRIPTION
CONTROLS COMMANDS / COMMANDES DU MENU CONTROL
xU VERU
Device
version.
Rd
0 65535 Example: 104 = Version 1.4
xI I_
Identification
number.
Rd
0 65535 Value displayed in hexadecimal in the device.
yo OPT
Options
available.
Rd
0 65535 0 = without option.
QE
EPD
2:2 pull down correction.
Rd/Wr
0
1
0 = off
1 = auto.
yl
LOCK
Key locking.
Rd/Wr
0
1
0 = unlocks
1 = locks
yi
EISP
Auto-lock
Rd/Wr
0
1
0 = off
1 = on.
ye
EPOS
Erase memories.
Rd/Wr
0
1
1 = erase all memories (automatic reset).
Y
FRES
DEFAULT VALUE.
Rd/Wr
0
1
1 = Default value action (automatic reset).
fr
BFCR
Red level adjustment of the FADE.
Rd/Wr
0
255
fb
BFCB
Blue level adjustment of the FADE.
Rd/Wr
0
255
fg
BFCG
Green level adjustment of the FADE.
Rd/Wr
0
255
COMMUNICATION PORT COMMANDS / COMMANDES DE COMMUNICATION
ne LANE
Communication
port
selection
Rd/Wr
0
1
0 = RS232
1 = LAN
nr
LANR
Reset of the LAN parameters.
Rd/Wr
0
1
1 = reset.
ns
LANS
Store the LAN parameters.
Rd/Wr
0
1
1 = store.
na ADIP
IP address and port selection (for
modification)
Rd/Wr
0 3
0 = all IP address / ports
1 = IP local address / local port
2 = IP remote address / remote port
3 = IP gateway address.
nw IPA_
First byte of the address selected by the
na command.
Rd/Wr
0 255
nx IPB_
Second byte of the address selected by
the na command.
Rd/Wr
0 255
ny IPC_
Third byte of the address selected by the
na command.
Rd/Wr
0 255
nz IPD_
Forth byte of the address selected by the
na command.
Rd/Wr
0 255
np PORT
Number of the port (local or remote)
selected by the na command.
Rd/Wr
0 65500
local port: 10000 to 10999.
remote port: 0 to 65500.
nk NTMK
Netmask.
Rd/Wr
0
24
Value = number of bit to 0 (from right).
example: 2
255.255.255.252
3
255.255.255.248
.............
8
255.255.255.0.............
24
255.0.0.0
nt
TCP
Protocol selection.
Rd/Wr
0
1
0 = UDP
1 = TCP
GENLOCK
COMMANDS
(ULTRA VIO only) / COMMANDES DU GENLOCK (ULTRA VIO uniquement)
GR
GENR
Genlock reference selection
Rd/Wr
0
3
0 = internal
1 = SDTV
2 = HDTV
3 = error
GA
GENA
Genlock reference status
Rd
0
3
0 = internal
1 = SDTV
2 = HDTV
3 = error
GF GENF
Genlock
type
Rd
0
10
0 = no signal.
1 = not compatible.
2 = NTSC (3.58/60).
3 = PAL (4.43/50).
4 = 1080i @ 50 Hz.
5 = 1080i @ 59.94 Hz.
6 = 1080i @ 60 Hz.
7 = 720p @ 50 Hz.
8 = 720p @ 59.94 Hz. 9 = 720p @ 60 Hz.
10 = 480p @ 60 Hz.
GT
GENT
Frame frequency of the genlock signal Rd
0 65535 Value in hundredth of Hz
GS GENS
Sub
carrier
adjustment of the genlock. Rd/Wr
0
255
GP GENP
Horizontal
adjustment on the genlock
Rd/Wr
0
127
GL
GENL
Genlock input load
Rd/Wr
0
1
0 = Hi-Z
1 = 75 ohms
OTHERS COMMANDS / AUTRES COMMANDES
yS
STO
Image parameters storing.
Rd/Wr
0
1
1 = STORE action (automatic reset).
? DEV
Device
type.
Rd
0 65535 30 = VIO1600
35 = ULTRA VIO
#
DEV...... Send all device parameters.
Rd
NOTE: Rd = Read only command / Commande de lecture.
Rd/Wr = Read and write command / Commande de lecture et d'écriture.
