526
13 Tableaux et sommaires
13.2 Distr
ibution des plots et câbles de r
a
ccor
d
ement pour les
int
e
rf
aces
de
données
Prise femelle RJ45 pour Interface Ethernet
Longueur câble max.: non blindé: 100 m
blindé: 400 m
Plot
Signal
Description
1
TX+
Transmit Data
2
TX–
Transmit Data
3
REC+
Receive Data
4
libre
5
libre
6
REC–
Receive Data
7
libre
8
libre
