EDGE Pro Ti CNC Manuel d’instructions 807662 Révision 2
Installation
Connexion plasma
Tableau 18 Brochage pour câble d’interface plasma générique
Utiliser les renseignements ci-dessous pour commander des câbles d’interface plasma.
N° contact
Signal
N° contact
Signal
1
+ 12 V
9
+ 12 V
2
Démarrage plasma +
10
Démarrage plasma –
3
Maintien de l’allumage +
11
Maintien de l’allumage –
4
Transfert +
12
Transfert –
5
Champ commun
13
Champ commun
6
Champ commun
14
Champ commun
7
Champ commun
15
Tension de l’arc
8
Terre
Nº de référence
Longueur
223358
3,05 m
223359
6,08 m
223360
7,62 m
223361
10,66 m
223362
15,25 m
223363
22,86 m
