OCTO range Chapter 11 : TECHNICAL SPECIFICATIONS (continued)
PAGE 43
11-4. MICROPHONE INPUT (jack 6.35 mm female stereo connector)
• Balanced.
• Vi = - 68 dBu (sens), - 62 dBu (sat).
• Zi = 600 Ω (balanced), 300 Ω unbalanced.
• Gain = 68 dB (maxi).
• High / low frequency filter = 1.3 kHz : ±3 steps.
• Compression: Ratio = 1:1 dB (linear), 2:1 dB.
Limiter = 10:1 (dB).
• Noise gate = - 54 dBu & - 63 dBu (max sens), expander threshold.
11-5. AUDIO OUTPUT (5-pin MCO male connector)
• Balanced and unbalanced stereo output.
• Vo = + 0 dBu (nominal), + 4 dBu (max).
• Zo = 600 Ω balanced.
• Zo = 300 Ω unbalanced.
• G = 0 dB nominal, - ∞ with Master volume.
11-6. COMMUNICATION PORTS
• RS-232 (on DB9 female connector)
Data Rate:
9600 Bauds, 8 data bits, 1 stop bit, no parity bit, no flow control.
• LAN (Optional on RJ45 connector)
Protocol:
UDP (User Datagram Protocol).
Data Rate: 10 / 100 Mbps.
LED functions (on RJ45 connector): Top LED Bottom LED Meaning
OFF OFF No link
OFF ON 100 BASE-T link.
ON OFF 10 BASE-T link.
11-7. ENVIRONMENTAL
Power Supply: Internal CE / UL / CSA / IEC 950 (50 W), universal, automatic.
Input: 100 VAC to 250 VAC; 50-60 Hz; I = 1 A Max.
Storage Temperature: - 25 °C to + 85 °C (- 13 °F to + 185 °F).
Operating temperature: 0 °C to + 50 °C (32 °F to 122 °F).
Maximum ambient operating temperature: < 40 °C (< 104 °F).
Hygrometry: 10% to 80% (without condensation).
Dimensions: D 300 x W 482 x H 44 mm / D 11.8" x W 19" x H 1.74".
Compatible with the 19" rack (height = 1 unit).
Weight: 3.7 kg / 8.16 lbs.
