OCTO range Chapter 6 : LCD FUNCTIONS DESCRIPTION (continued)
PAGE 25
7 [EFFECT] + ENTER (available on the OCTO-FADE ™ and the OCTO-FX ™ only).
7-1 [fade timing] + ENTER.
Adjust the fade timing when switching with
+ ENTER.
7-2 [shadow title] + ENTER.
This function allows displaying a shadow bar onto the output. Select [ON] with
+ ENTER to display the
shadow bar, and adjust the shadow bar with the following function.
• [shadow V size] = Allows to adjust the vertical size of the shadow bar.
• [shadow V position ] = Allows to adjust the vertical position of the shadow bar.
8 [CONTROL] + ENTER.
8-1 [versions] + ENTER.
Version _._= update version. I = Identification number. K, S, F, O, V = status of the internal firmware versions.
8-2 [key locking] + ENTER.
Select an item with
and change the mode with ENTER.
• [menus] = Locks/unlocks the LCD CONTROL switches.
• [input] = Locks/unlocks the INPUT SELECTION and FREEZE switches.
• [all] =
Locks/unlocks all the front panel switches.
NOTE: To unlock presses simultaneously on ENTER and EXIT.
• [autolock] = Allows to select an input only if a signal is connected.
8-3 [transition] + ENTER.
Select an item with
+ ENTER
8-3-1 [fade color] + ENTER.
This function allows selecting the color of the fade during the transition. Select a color (red, green and bleu)
with
+ ENTER and adjust the level with + ENTER. During the adjustment the color is
displayed onto the output. To obtain the black color, set the 3 levels to the minimum. To obtain the white
color, set the 3 levels to maximum. To obtain the grey color, set the 3 levels in the middle.
8-3-2 [fade frame] + ENTER (available on the OCTO-LOGO ™ and the OCTO-FX ™ only).
This function allows switching by a fading image (instead of a color). Adjust the duration of the transition
with
+ ENTER.
8-3-3 [clean cut] + ENTER.
This function allows a clean switching thanks to a fast freeze of the displayed source. Select a function with
+ ENTER.
• [from computer] = The CLEAN CUT operates only when switching from a computer source. The others
switching operates with a fade color.
• [from video] = The CLEAN CUT operates only when switching from a computer source. The others
switching operates with a fade color.
• [from all] = The CLEAN CUT operates when switching from all sources.
NOTE: The FRAME is not available when the CLEAN CUT is activated.
8-4 [freeze button] + ENTER (available on the OCTO-LOGO ™ only).
Allows assigning a new function to the front panel FREEZE button. Select an item and validate with ENTER.
• [freeze] = The FREEZE button allows to freeze the displayed image.
• [logo] = The FREEZE button allows to switch ON or OFF the logos of the displayed image.
8-4 [effect key] + ENTER (available on the OCTO-FADE ™ and the OCTO-FX ™ only).
This function allows assigning effects to the input key. Select an item with + ENTER.
• [cut fade title] = Assign the 3 effects to the EFFECT key.
• [cut fade] = Assign CUT & FADE only to the EFFECT key.
• [cut title] = Assign CUT & TITLE only to the EFFECT key.
• [title fade] = Assign TITLE & FADE only to the EFFECT key.
8-5 [2:2 pull down] + ENTER.
Select an item and validate with ENTER.
• [auto] = Automatic recognition and correction of the 2:2 pull down.
• [off] = Disable the 2:2 pull down correction.
