Chapter 9 : REMOTE CONTROL PROGRAMMER'S GUIDE (continued) OCTO range
PAGE 36
9-4. COMMANDS AND RESPONSES TABLE (continued)
ASCII RESPONSE COMMAND TYPE VALUE
COMMAND DESCRIPTION MIN MAX DESCRIPTION
FRAME & LOGOS COMMANDS (OCTO-LOGO ™ & OCTO-FX ™ only)
PC PCH Input selection for adjustment. Rd/Wr 0 8
0 = All inputs 1 = INPUT #1
2 = INPUT #2................ 8 = INPUT #8
** LM LMOD Frame/logo mode. Rd/Wr 0 4
0 = use & assignment mode.
1 = logo recording mode.
2 = frame recording mode.
3 = auto list mode (display all logo parameters).
4 = erasing mode.
** LI LIND Index selection (according to PCH) . Rd/Wr 0 1 0 = index 1 1 = index 2
** LP LPLG
Logo & frame assignment (according to
PCH & LIND. And LMOD = 0).
Rd/Wr 0 1
0 = none 1 = frame
2 = logo 1................... 9 = logo 8
** LC LCUR
• In use mode: Logo/frame in using
process.
• In logo recording mode: Number of
the logo to be store (always >1).
• In frame recording mode: Number of
the frame to be store (always = 1).
• In erase mode: number of the logo to
be erase (0 = erase all).
Rd/Wr 0 9
0 = no logo
1 = frame
2 = logo 1
3 = logo 2
4 = logo 3
5 = logo 4
....
9 = logo 8
** LE LEMP
Status of the frame/logo memories
(according to LCUR).
Rd 0 1
0 = logo/frame memorized.
1 = empty memory.
** Lh LHPO Horizontal position of the logo area. Rd/Wr 0 255
** Lv LVPO Vertical position of the logo area. Rd/Wr 0 255
** LH LHSZ Horizontal size of the logo area. Rd/Wr 5 255 5 = 3% 255 = 100%
** LV LVSZ Vertical size of the logo area. Rd/Wr 5 255 5 = 3% 255 = 100%
** LL LLEV Luma key level. Rd/Wr 0 255
** Lb LBKC Background color. Rd/Wr 0 7
** LS LSTO
• In recording mode: frame/logo storing.
• In erase mode: frame/logo erasing.
Rd 0 1 1 = STORE or ERASE (automatic reset).
** Lo LOFM Output format during the logo storing. Rd 0 11 Identical as F command.
** LA LABT Stop the frame storing. Rd/Wr 0 1 1 = stop the frame storing (automatic reset).
** Lt LSTY Frame/logo type. Rd 0 1 0 = frame 1 = logo
** Ls LSTA Status of the logo programmer Rd 0 5
0 = free.
1 = logo/frame in recalling process.
2 = logo/frame in storing process.
3 = output format incompatible with the logo.
4 = logo/frame in consulting process.
5 = logo/frame in erasing process.
** Lp LPIX Pixels number in a line of the logo area. Rd 0 65535
** Ll LLIN Lines number in a logo area. Rd 0 65535
These 2 commands allow to calculate the
duration of the storing.
** Ld LLD Fade logo duration (0.02 second step). Rd/Wr 15 255 15 = 0.3 second 255 = 5.1 seconds
** LD LDYS Display logo (according to PCH) Rd/Wr 0 1 0 = Display OFF 1 = Display ON
NOTE: To store a logo you should:
c Select the logo recording mode with the LM command (1LM).
d Adjust the position and size of the logo area with the Lh, Lv, LH and LV commands.
e Adjust the luma key level (with LL command) and the background color (with Lb command).
f Select a logo memory with the LC command.
g Make a store with LS command (1LS).
To store a frame you should:
c Select the frame recording mode with the LM command (2LM).
d Make a store with the LS command (1LS).
NOTE: To assign a logo/frame to an input you should:
c Select the assignment mode with the LM command (0LM).
d Select the input with the PC command.
e Select an index (1 or 2) with the LI command.
f Select a stored logo/frame with LP command.
g Adjust the horizontal & vertical position of the logo with the Lh & Lv commands.
NOTE: * = command available on the OCTO-FADE ™ & OCTO-FX ™ only. Rd = Read only command.
** = command available on the OCTO-LOGO ™ & OCTO-FX ™ only. Rd/Wr = Read and write command.
