OCTO range Chapter 6 : LCD FUNCTIONS DESCRIPTION (continued)
PAGE 23
5 [AUDIO] + ENTER.
5-1 [master volume] + ENTER.
Adjust the audio output level with
+ ENTER.
5-2 [audio source] + ENTER.
Select an item with
+ ENTER:
• [auto follow] = The audio follows the video image.
• [input --] =
The selected audio input (is permanently diffused).
5-3 [audio level] + ENTER.
This function allows to separately adjust the level of each audio input. Adjust the level with
+ ENTER.
NOTE: This function acts on the selected (diffused) audio input.
5-4 [audio balance] + ENTER.
This function allows adjusting for each input the audio balance. Adjust the level with
+ ENTER.
NOTE: This function acts on the selected (diffused) audio input.
5-5 [mic. control] + ENTER.
Select an item with
+ ENTER:
5-5-1 [tone] + ENTER.
Adjust the microphone tone with
+ ENTER.
5-5-2 [compression] + ENTER.
Select an item with
+ ENTER.
• [no] = linear output versus input.
• [2/1] = the output is compressed in order to reduce the dynamic.
5-5-3 [noise gate] + ENTER.
Adjust the noise gate threshold with
+ ENTER.
NOTE: This function eliminates very low noises.
5-5-4 [voice over] + ENTER. This menu is available with the voice over option only (OPT-VOV802).
This option allows to automatically tone down the audio background when the microphone is used. Select an
adjustment with
+ ENTER.
5-5-4-1 [threshold] + ENTER.
Adjust the threshold level of the toning down with
+ ENTER.
5-5-4-2 [depth] + ENTER.
Adjust the toning down level with
+ ENTER.
5-5-4-3 [release time] + ENTER.
Adjust the release time of the audio background with
+ ENTER.
• [fast] = 0.5 second.
• [slow] = 2 seconds.
5-6 [mute off] + ENTER.
Switch ON or OFF the audio output. Validate with ENTER.
