Chapter 6 : LCD FUNCTIONS DESCRIPTION (continued) OCTO range
PAGE 24
6 [LOGOS/FRAME] + ENTER (available on the OCTO-LOGO ™ and the OCTO-FX ™ only).
6-1 [use logo/frame] + ENTER.
Select an item with
+ ENTER.
6-1-1 [display] + ENTER.
This function allows to display ON or OFF the assigned logos of each input. Select an input with and
press ENTER to display ON or OFF.
NOTE: To display a logo or a frame, the output format should be the same that the output format used
during the storing.
6-1-2 [assignment] + ENTER.
This function allows assigning the stored frame and the logos to the inputs of the OCTO-LOGO
™ (up to 2
logos at the same time).
c Select an input with + ENTER.
d Select the INDEX 1 or the INDEX 2 with + ENTER.
e Then select a logo, frame or none with + ENTER.
f Adjust the logo position with H& V position functions.
6-1-3 [fade duration] + ENTER.
This function allows adjusting the fade duration of the logo when you display ON or OFF a logo. Adjust the
duration with
and validate with ENTER.
6-2 [record logo] + ENTER.
This mode allows storing up to 8 logos in order to incrust them into the displayed image (up to 2 logos at a same
time). Select an item with
+ ENTER.
6-2-1 [H position] + ENTER.
Adjust the Horizontal position of the logo area with
+ ENTER.
6-2-2 [V position] + ENTER.
Adjust the Vertical position of the logo area with
+ ENTER.
6-2-3 [H size] + ENTER.
Adjust the Horizontal size of the logo area with
+ ENTER.
6-2-4 [V size] + ENTER.
Adjust the Vertical size of the logo area with
+ ENTER.
NOTE: The logo area is limited at an eighth (1/8) of the displayed area.
6-2-5 [luma key level] + ENTER.
This function allows to "erase" the darkest portions of your logo area in order to make special logo contour.
Adjust the luma key level with
+ ENTER.
6-2-6 [back. color] + ENTER.
This function allows coloring the "erased portions" of the logo when using the luma key. Select a level with
+ ENTER.
6-2-7 [store] + ENTER.
This function allows storing the logo into one of the 8 memories. Select a logo memory with
+
ENTER. The memorization will take few seconds.
6-3 [record frame] + ENTER.
This mode allows storing a frame in order to display it at any time during the show.
6-3-1 [store]
This function allows storing the displayed image (frame) into a memory. Presses ENTER to start the
memorization of the frame. The memorization will take about 2 minutes.
6-4 [erase mode] + ENTER.
This function allows erasing the memorized frame and/or the logos. Select an item with
+ ENTER.
