Chapter 6 : LCD FUNCTIONS DESCRIPTION (continued) OCTO range
PAGE 22
4 [IMAGE] + ENTER.
WARNING: In Seamless mode this menu is not available for the "reference" Computer source.
NOTE: The image menu contents will be different in case of computer or video on the input selected.
4-1 [centering] + ENTER.
Adjust automatically the image in the centering pattern.
4-2 [pos. settings] + ENTER.
Select one of the following function with
+ ENTER.
4-2-1 [H position] + ENTER.
Adjust the Horizontal position with
+ ENTER.
4-2-2 [V position] + ENTER.
Adjust the Vertical position with
+ ENTER.
4-2-3 [H size] + ENTER.
Adjust the Horizontal size with
+ ENTER.
4-2-4 [V size] + ENTER.
Adjust the Vertical size with
+ ENTER.
4-3 [aspect ratio] + ENTER.
Select the Aspect Ratio of your input source with
+ ENTER.
• [4/3 standard] = 4/3 input format. • [16/9 letterbox] = Letterbox input format.
• [WS anamorphic] = Widescreen Anamorphic input format (video) or 16/9 input format (computer).
4-4 [H. smooth] + ENTER.
Adjust the horizontal smooth with
+ ENTER.
• If the selected input is a VIDEO signal (LCD menu # 1-2 =SDTV---) the IMAGE MENU displays the following items:
4-5 [brightness] + ENTER.
Adjust the Brightness with
+ ENTER.
4-6 [contrast] + ENTER.
Adjust the Contrast with
+ ENTER.
4-7 [color] + ENTER.
Adjust the Color with
+ ENTER.
4-8 [hue] + ENTER.
Adjust the Tint of the picture (NTSC only) with
+ ENTER.
4-9 [u / over scan] + ENTER.
Select Underscan or Overscan with
+ ENTER.
• [underscan] = Underscan mode. The entire image is visible on the screen. Computer mode is underscan.
• [overscan] = Overscan mode. The image is displayed about 8 % bigger than in underscan mode, to avoid
seeing the corners and the borders. Standard TV display mode is overscan.
4-10 [sharpness] + ENTER.
This function allows increasing the sharpness of the image. Select a level with
+ ENTER.
4-11 [preset] + ENTER.
This function allows setting all the image parameters to the factory settings. Select [YES] and validate with ENTER.
• If the selected input is a COMPUTER signal (LCD menu # 1-2 = Computer---) the IMAGE MENU displays:
4-5 [black level] + ENTER.
Adjust the black level with
+ ENTER.
4-6 [color] + ENTER.
Select a color (Red, Green, or Bleu) with
+ ENTER and adjust the level with + ENTER.
4-7 [optimize] + ENTER.
Select an item with
+ ENTER.
• [clock] = Manual adjustment of the pixel clock.
• [phase] = Manual adjustment of the pixel phase.
4-8 [preset] + ENTER.
This function allows setting all the image parameters to the factory settings. Select [YES] and validate with ENTER.
